Ball-Ended Thrust Screws, Steel
- Volume Discount
Type A: with full ball. Type B: with flat-faced ball, to clamp surfaces that are not exactly parallel. Temperature range: -60ºC to +350ºC.
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Product data
- CAD data not available
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Shape | Thread size d1 (mm) | Nominal length (mm) | d3 (mm) | Total length shape A l1 (mm) | Total length shape B l2 (mm) | Ball diameter (mm) | Wrench size SW (mm) | Max. load (kN) | Weight (g) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
6.75 € | 1 | Available | 4 Days | A | M 3 | 5 | - | 5 | - | 1.5 | 1.5 | 2.5 | 0.15 | |
6.80 € | 1 | Available | 4 Days | A | M 3 | 8 | - | 7.5 | - | 1.5 | 1.5 | 2.5 | 0.22 | |
6.89 € | 1 | Available | 4 Days | A | M 3 | 10 | - | 10 | - | 1.5 | 1.5 | 2.5 | 0.33 | |
4.89 € | 1 | Available | 4 Days | A | M 4 | 6 | - | 6 | - | 2.5 | 2 | 3.5 | 0.4 | |
4.95 € | 1 | Available | 4 Days | A | M 4 | 10 | - | 10 | - | 2.5 | 2 | 3.5 | 0.7 | |
4.95 € | 1 | Available | 4 Days | A | M 4 | 16 | - | 16 | - | 2.5 | 2 | 3.5 | 1.1 | |
4.50 € | 1 | Available | 4 Days | A | M 5 | 8 | - | 8 | - | 3 | 2.5 | 4.5 | 0.8 | |
4.50 € | 1 | Available | 4 Days | A | M 5 | 12 | - | 12 | - | 3 | 2.5 | 4.5 | 1.3 | |
4.74 € | 1 | Available | 4 Days | A | M 5 | 20 | - | 20 | - | 3 | 2.5 | 4.5 | 2.3 | |
4.50 € | 1 | Available | 4 Days | A | M 6 | 10 | - | 10.8 | - | 4 | 3 | 9 | 1.5 | |
4.50 € | 1 | Available | 4 Days | A | M 6 | 16 | - | 16.8 | - | 4 | 3 | 9 | 2.4 | |
4.74 € | 1 | Available | 4 Days | A | M 6 | 25 | - | 25.8 | - | 4 | 3 | 9 | 3.9 | |
4.50 € | 1 | Available | 4 Days | A | M 8 | 10 | - | 11.2 | - | 5.5 | 4 | 15 | 2.6 | |
4.50 € | 1 | Available | 4 Days | A | M 8 | 12 | - | 13.2 | - | 5.5 | 4 | 15 | 3.2 | |
4.50 € | 1 | Available | 4 Days | A | M 8 | 20 | - | 21.2 | - | 5.5 | 4 | 15 | 5.7 | |
4.74 € | 1 | Available | 4 Days | A | M 8 | 30 | - | 31.2 | - | 5.5 | 4 | 15 | 8.9 | |
5.36 € | 1 | Available | 4 Days | A | M 10 | 12 | - | 13.7 | - | 7 | 5 | 20 | 5 | |
5.36 € | 1 | Available | 4 Days | A | M 10 | 16 | - | 17.7 | - | 7 | 5 | 20 | 6.8 | |
5.55 € | 1 | Available | 4 Days | A | M 10 | 25 | - | 26.7 | - | 7 | 5 | 20 | 11.2 | |
5.71 € | 1 | Available | 4 Days | A | M 10 | 35 | - | 36.7 | - | 7 | 5 | 20 | 16.2 | |
6.08 € | 1 | Available | 4 Days | A | M 12 | 16 | - | 18 | - | 8.5 | 6 | 30 | 10 | |
6.08 € | 1 | Available | 4 Days | A | M 12 | 20 | - | 22 | - | 8.5 | 6 | 30 | 12.4 | |
6.63 € | 1 | Available | 4 Days | A | M 12 | 30 | - | 32 | - | 8.5 | 6 | 30 | 19.6 | |
7.25 € | 1 | Available | 4 Days | A | M 12 | 40 | - | 42 | - | 8.5 | 6 | 30 | 28.5 | |
9.94 € | 1 | Available | 4 Days | A | M 16 | 20 | - | 23.3 | - | 12 | 8 | 60 | 22 | |
9.94 € | 1 | Available | 4 Days | A | M 16 | 25 | - | 28.3 | - | 12 | 8 | 60 | 28 | |
10.38 € | 1 | Available | 4 Days | A | M 16 | 35 | - | 38.3 | - | 12 | 8 | 60 | 41 | |
10.98 € | 1 | Available | 4 Days | A | M 16 | 50 | - | 53.3 | - | 12 | 8 | 60 | 48 | |
25.34 € | 1 | Available | 4 Days | A | M 20 | 30 | - | 34.2 | - | 15 | 10 | 90 | 52 | |
26.34 € | 1 | Available | 4 Days | A | M 20 | 40 | - | 44.2 | - | 15 | 10 | 90 | 72 | |
26.34 € | 1 | Available | 4 Days | A | M 20 | 50 | - | 54.2 | - | 15 | 10 | 90 | 93 | |
29.03 € | 1 | Available | 4 Days | A | M 20 | 60 | - | 64.2 | - | 15 | 10 | 90 | 115 | |
8.87 € | 1 | Available | 4 Days | B | M 4 | 6 | 1.8 | - | 5.6 | 2.5 | 2 | 3.5 | 0.4 | |
9.06 € | 1 | Available | 4 Days | B | M 4 | 10 | 1.8 | - | 9.6 | 2.5 | 2 | 3.5 | 0.7 | |
9.15 € | 1 | Available | 4 Days | B | M 4 | 16 | 1.8 | - | 15.6 | 2.5 | 2 | 3.5 | 1.1 | |
9.29 € | 1 | Available | 4 Days | B | M 5 | 8 | 2.2 | - | 7.5 | 3 | 2.5 | 4.5 | 0.8 | |
9.50 € | 1 | Available | 4 Days | B | M 5 | 12 | 2.2 | - | 11.5 | 3 | 2.5 | 4.5 | 1.3 | |
9.69 € | 1 | Available | 4 Days | B | M 5 | 20 | 2.2 | - | 19.5 | 3 | 2.5 | 4.5 | 2.3 | |
7.88 € | 1 | Available | 4 Days | B | M 6 | 10 | 3 | - | 10 | 4 | 3 | 9 | 1.5 | |
8.06 € | 1 | Available | 4 Days | B | M 6 | 16 | 3 | - | 16 | 4 | 3 | 9 | 2.4 | |
8.15 € | 1 | Available | 4 Days | B | M 6 | 25 | 3 | - | 25 | 4 | 3 | 9 | 3.9 | |
9.21 € | 1 | Available | 4 Days | B | M 8 | 10 | 5 | - | 10 | 5.5 | 4 | 15 | 2.6 | |
9.21 € | 1 | Available | 4 Days | B | M 8 | 12 | 5 | - | 12 | 5.5 | 4 | 15 | 3.2 | |
9.33 € | 1 | Available | 4 Days | B | M 8 | 20 | 5 | - | 20 | 5.5 | 4 | 15 | 5.7 | |
9.44 € | 1 | Available | 4 Days | B | M 8 | 30 | 5 | - | 30 | 5.5 | 4 | 15 | 8.9 | |
9.33 € | 1 | Available | 4 Days | B | M 10 | 12 | 6 | - | 12 | 7 | 5 | 20 | 5 | |
9.44 € | 1 | Available | 4 Days | B | M 10 | 16 | 6 | - | 16 | 7 | 5 | 20 | 6.8 | |
9.75 € | 1 | Available | 4 Days | B | M 10 | 25 | 6 | - | 25 | 7 | 5 | 20 | 11.2 | |
9.99 € | 1 | Available | 4 Days | B | M 10 | 35 | 6 | - | 35 | 7 | 5 | 20 | 16.2 | |
12.91 € | 1 | Available | 4 Days | B | M 12 | 16 | 7 | - | 16 | 8.5 | 6 | 30 | 10 | |
12.92 € | 1 | Available | 4 Days | B | M 12 | 20 | 7 | - | 20 | 8.5 | 6 | 30 | 12.4 | |
13.35 € | 1 | Available | 4 Days | B | M 12 | 30 | 7 | - | 30 | 8.5 | 6 | 30 | 19.6 | |
13.74 € | 1 | Available | 4 Days | B | M 12 | 40 | 7 | - | 40 | 8.5 | 6 | 30 | 28.5 | |
20.09 € | 1 | Available | 4 Days | B | M 16 | 20 | 11 | - | 20 | 12 | 8 | 60 | 22 | |
20.52 € | 1 | Available | 4 Days | B | M 16 | 25 | 11 | - | 25 | 12 | 8 | 60 | 28 | |
20.91 € | 1 | Available | 4 Days | B | M 16 | 35 | 11 | - | 35 | 12 | 8 | 60 | 41 | |
21.32 € | 1 | Available | 4 Days | B | M 16 | 50 | 11 | - | 50 | 12 | 8 | 60 | 48 | |
41.13 € | 1 | Available | 4 Days | B | M 20 | 30 | 13.5 | - | 30 | 15 | 10 | 90 | 52 | |
41.45 € | 1 | Available | 4 Days | B | M 20 | 40 | 13.5 | - | 40 | 15 | 10 | 90 | 72 | |
41.82 € | 1 | Available | 4 Days | B | M 20 | 50 | 13.5 | - | 50 | 15 | 10 | 90 | 93 |
