Thrust Pads with Spring Retainer According to DIN 6311 and Factory Standard, Stainless Steel

Thrust Pads with Spring Retainer According to DIN 6311 and Factory Standard, Stainless Steel

Part number:

Still undefined. 6 possible part numbers found.
Quantity:

Part number list

Number of items
  • 1
    • Part number
    65499106
    65499108
    65499110
    65499112
    65499116
    65499120

    For bolts/gub screws

    Outer diameter d1

    (mm)

    d2H12

    (mm)

    d4

    (mm)

    Height h1

    (mm)

    h2

    (mm)

    t1

    (mm)

    Weight

    (g)

    		Minimum order quantity
    M 6 DIN6332
    12
    4.6
    10
    7
    2.5
    4
    4.4
    1 pieces
    M 8 DIN6332
    16
    6.1
    12
    9
    4
    5
    9
    1 pieces
    M 10 DIN6332
    20
    8.1
    15
    11
    5
    6
    17
    1 pieces
    M 12 DIN6332
    25
    8.1
    18
    13
    6
    7
    33
    1 pieces
    M 16 DIN6332
    32
    12.1
    22
    15
    7
    7.5
    57
    1 pieces
    M 20 DIN6332
    40
    15.6
    28
    16
    9
    8
    103
    1 pieces
    Unit price (excluding VAT)(Unit price including VAT)
    Standard shipping days
    1.65 €
    ( 1.96 € )
    4 working days
    1.77 €
    ( 2.11 € )
    4 working days
    2.17 €
    ( 2.58 € )
    4 working days
    2.71 €
    ( 3.22 € )
    4 working days
    3.78 €
    ( 4.50 € )
    4 working days
    5.75 €
    ( 6.84 € )
    4 working days
  • 1

    • More Information

    Basic information

    Material: Stainless steel 1.4301 (AISI 304).
    Spring retainer included.
    Up to size d1= 40 mm for grub screws according to DIN 6332. From size d1= 48 mm for grub screws according to factory standard.
