Hollow wall compact distribution board
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Part Number
|
|---|
| KLV-12HWP-F |
| KLV-24HWP-F |
| KLV-36HWM-F |
| KLV-36HWP-F |
| KLV-48HWM-F |
| KLV-48HWP-F |
| KLV-48HWP-F-VM |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Mounting method | Model | Height (mm) | RAL-number | With mounting plate | Built-in depth (mm) | Number of rows | Type of cover | Number of mountable connection strips | Mounting dimension (standardised) | With connecting lugs | EMC-version | Extension possible | Internal depth (mm) | DIN-rail | Material housing | Material | Width in number of modular spacings | Max. number of dual cores | Type of closure | Transparent cover/door | With lock | DIN-compatible | 110-compatible | LSA | Cover model | SID | Degree of protection (NEMA) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
209.68 € | 1 | 3 Days | Hollow wall | - | 340 | 9016 | false | 88 | 1 | Door | - | - | - | true | true | 75 | true | Plastic | - | 12 | - | Other | false | false | - | - | - | With notch | - | - | ||
262.89 € | 1 | 3 Days | Hollow wall | - | 465 | 9016 | false | 88 | 2 | Door | - | - | - | true | true | 75 | true | Plastic | - | 12 | - | Other | false | false | - | - | - | With notch | - | - | ||
507.50 € | 1 | 3 Days | Flush mounted (plaster) | Distributor enclosure | 590 | - | - | - | - | - | 0 | Other | false | - | - | - | - | - | Steel plate/plastic | - | 12 | - | - | - | true | true | false | - | false | Other | ||
297.89 € | 1 | 3 Days | Hollow wall | - | 590 | 9016 | false | 88 | 3 | Door | - | - | - | true | true | 75 | true | Plastic | - | 12 | - | Other | false | false | - | - | - | With notch | - | - | ||
552.43 € | 1 | 3 Days | Flush mounted (plaster) | Distributor enclosure | 715 | - | - | - | - | - | 0 | Other | false | - | - | - | - | - | Steel plate/plastic | - | 12 | - | - | - | true | true | false | - | false | Other | ||
414.34 € | 1 | 3 Days | Hollow wall | - | 715 | 9016 | false | 88 | 4 | Door | - | - | - | true | true | 75 | true | Plastic | - | 12 | - | Other | false | false | - | - | - | With notch | - | - | ||
3,536.19 € | 1 | 5 Days | Hollow wall | - | 715 | 9016 | false | 87.5 | 4 | Door | - | - | - | false | true | 77 | true | Plastic | - | 12 | - | Other | false | false | - | - | - | Closed | - | - |
Loading...
Basic information
| Colour | White | Width(mm) | 360 | Depth(mm) | 100 |
|---|---|---|---|---|---|
| Degree of protection (IP) | IP30 |
Configure
Basic Attributes
-
Mounting method
-
Model
-
Height(mm)
-
RAL-number
-
With mounting plate
-
Built-in depth(mm)
-
Number of rows
-
Type of cover
-
Number of mountable connection strips
-
Mounting dimension (standardised)
-
With connecting lugs
-
EMC-version
-
Extension possible
-
Internal depth(mm)
-
DIN-rail
-
Material housing
-
Material
-
Width in number of modular spacings
-
Max. number of dual cores
-
Type of closure
-
Transparent cover/door
-
With lock
-
DIN-compatible
-
110-compatible
-
LSA
-
Cover model
-
SID
-
Degree of protection (NEMA)
Filter by standard shipping days
-
- All
- 3 Days or Less
- 5 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
