Configure

Colour
Core layout
Core layout(mm)
Cross section (based on core number) (part 1 + 2)
Cross section (each core) (part 1)(mm²)
- 2.50
- 4
- 6
- 10
- 16
- 25
- 35
Insulation material
- PVC
Manufacturer part #
- 607119
- 607147
- 607195
- 607225
- 607271
- 607295
- 607316
- 607341
- 607363
- 607387
- 607407
- 607432
- 1386603
- 1386607
Max. temperature range (fixed installation)(°C)
- +70
Max. temperature range (flexible installation)(°C)
- +70
Min. temperature range (fixed installation)(°C)
- -20
Min. temperature range (flexible installation)(°C)
- -20
Outside diameter(mm)
- 4.20
- 4.60
- 5
- 6.20
- 7.76
- 9.76
- 11.35
Type (manufacturer type)
Est. shipping days
- All
- Within 3 working days

Earth cable【1 to 5 pieces】

Earth cable

Catalog

Part number:

Still undefined. 14 possible part numbers found.

Part number list
Catalog

Part number list

Number of items

Part number

1564516
1565200
1565201
1567033
1567035
1567036
1567037
1567038
1567039
1567040
1568965
1568968
1571438
1572240

Colour

Core layout

Core layout

(mm)

Cross section (based on core number) (part 1 + 2)

Cross section (each core) (part 1)

(mm²)

Insulation material

Manufacturer part #

Max. temperature range (fixed installation)

(°C)

Max. temperature range (flexible installation)

(°C)

Min. temperature range (fixed installation)

(°C)

Min. temperature range (flexible installation)

(°C)

Outside diameter

(mm)

Type (manufacturer type)

Minimum order quantity

Red\|Transparent	7 x 56 x 0.18 mm	7 x 56 x 0.18	1 x 10 mm²	10	-	607195	-	-	-	-	6.20	CCA	1 packs 5 pieces
Blue\|Transparent	7 x 3 x 30 x 0.18 mm	7 x 3 x 30 x 0.18	1 x 16 mm²	16	-	607316	-	-	-	-	7.76	CCA	1 packs 5 pieces
Blue\|Transparent	7 x 3 x 47 x 0.18 mm	7 x 3 x 47 x 0.18	1 x 25 mm²	25	-	607387	-	-	-	-	9.76	CCA	1 packs 5 pieces
Black\|Transparent	7 x 56 x 0.18 mm	7 x 56 x 0.18	1 x 10 mm²	10	-	607225	-	-	-	-	6.20	CCA	1 packs 5 pieces
Red\|Transparent	7 x 3 x 30 x 0.18 mm	7 x 3 x 30 x 0.18	1 x 16 mm²	16	-	607271	-	-	-	-	7.76	CCA	1 packs 5 pieces
Black\|Transparent	7 x 3 x 30 x 0.18 mm	7 x 3 x 30 x 0.18	1 x 16 mm²	16	-	607295	-	-	-	-	7.76	CCA	1 packs 5 pieces
Red\|Transparent	7 x 3 x 47 x 0.18 mm	7 x 3 x 47 x 0.18	1 x 25 mm²	25	-	607341	-	-	-	-	9.76	CCA	1 packs 5 pieces
Black\|Transparent	7 x 3 x 47 x 0.18 mm	7 x 3 x 47 x 0.18	1 x 25 mm²	25	-	607363	-	-	-	-	9.76	CCA	1 packs 5 pieces
Red\|Transparent	7 x 7 x 29 x 0.18 mm	7 x 7 x 29 x 0.18	1 x 35 mm²	35	-	607407	-	-	-	-	11.35	CCA	1 packs 5 pieces
Black\|Transparent	7 x 7 x 29 x 0.18 mm	7 x 7 x 29 x 0.18	1 x 35 mm²	35	-	607432	-	-	-	-	11.35	CCA	1 packs 5 pieces
Red	98 x 0.18 mm	98 x 0.18	1 x 2.50 mm²	2.50	PVC	1386603	+70	+70	-20	-20	4.20	93030 c 469	1 pieces
Black	7 x 23 x 0.18 mm	7 x 23 x 0.18	1 x 4 mm²	4	PVC	1386607	+70	+70	-20	-20	5	93030 c 473	1 pieces
Red\|Transparent	7 x 34 x 0.18 mm	7 x 34 x 0.18	1 x 6 mm²	6	-	607119	-	-	-	-	4.60	CCA	1 packs 5 pieces
Black\|Transparent	7 x 34 x 0.18 mm	7 x 34 x 0.18	1 x 6 mm²	6	-	607147	-	-	-	-	4.60	CCA	1 packs 5 pieces

Unit price (excluding VAT)(Unit price including VAT)	Standard shipping days

20.23 € ( 24.07 € )	3 working days
24.48 € ( 29.13 € )	3 working days
33.21 € ( 39.52 € )	3 working days
21.29 € ( 25.34 € )	3 working days
23.41 € ( 27.86 € )	3 working days
23.41 € ( 27.86 € )	3 working days
36.43 € ( 43.35 € )	3 working days
36.43 € ( 43.35 € )	3 working days
62.87 € ( 74.82 € )	3 working days
53.11 € ( 63.20 € )	3 working days
7.88 € ( 9.38 € )	3 working days
12.67 € ( 15.08 € )	3 working days
12.67 € ( 15.08 € )	3 working days
13.75 € ( 16.36 € )	3 working days

Catalog

Products homepage

Catalog (2-page spread)
