U terminal
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Part Number
|
|---|
| 60C6 |
| 92C4 |
| 93C6 |
| 94C6 |
| 94C8 |
| 95C6 |
| 95C8 |
| 96C5 |
| 96C6 |
| 96C8 |
| 97C5 |
| 97C6 |
| 1650C5 |
| 652C5 |
| 652C6 |
| 653C6 |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Colour | Contact material | Cross-section range | Cross section (max.) (mm²) | Insulation type | Manufacturer part # | Min. cross section (mm²) | Thread size | Type (manufacturer type) | RoHS-compliant | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
9.45 € | 1 | Available | 3 Days | Silver | Nickel plated | 16 mm² (max) | 16 | Not insulated | 60C6 | - | M6 | 60C6 | Yes | |
0.32 € | 1 | Available | 3 Days | Silver | Copper silver plated | 1.5 mm² (max) | 1.5 | Not insulated | 92C4 | - | M4 | 92C4 | - | |
0.39 € | 1 | Available | 3 Days | Silver | Copper silver plated | 2.5 mm² (max) | 2.5 | Not insulated | 93C6 | - | M6 | 93C6 | - | |
0.45 € | 1 | Available | 3 Days | Silver | Copper silver plated | 4 mm² (max) | 4 | Not insulated | 94C6 | - | M6 | 94C6 | - | |
0.73 € | 1 | Available | 3 Days | Silver | Copper silver plated | 4 mm² (max) | 4 | Not insulated | 94C8 | - | M8 | 94C8 | - | |
0.55 € | 1 | Available | 3 Days | Silver | Copper silver plated | 6 mm² (max) | 6 | Not insulated | 95C6 | - | M6 | 95C6 | - | |
0.71 € | 1 | Available | 3 Days | Silver | Copper silver plated | 6 mm² (max) | 6 | Not insulated | 95C8 | - | M8 | 95C8 | - | |
0.85 € | 1 | Available | 3 Days | Silver | Copper silver plated | 10 mm² (max) | 10 | Not insulated | 96C5 | - | M5 | 96C5 | - | |
0.79 € | 1 | Available | 3 Days | Silver | Copper silver plated | 10 mm² (max) | 10 | Not insulated | 96C6 | - | M6 | 96C6 | - | |
0.88 € | 1 | Available | 3 Days | Silver | Copper silver plated | 10 mm² (max) | 10 | Not insulated | 96C8 | - | M8 | 96C8 | - | |
1.33 € | 1 | Available | 3 Days | Silver | Copper silver plated | 16 mm² (max) | 16 | Not insulated | 97C5 | - | M5 | 97C5 | - | |
1.33 € | 1 | Available | 3 Days | Silver | Copper silver plated | 16 mm² (max) | 16 | Not insulated | 97C6 | - | M6 | 97C6 | - | |
0.29 € | 1 | Available | 3 Days | Silver | Copper silver plated | 4 - 6 mm² | 6 | Not insulated | 1650C5 | 4 | M5 | 1650C5 | - | |
1.33 € | 1 | Available | 3 Days | Red | Copper silver plated | 10 mm² (max) | 10 | Partially insulated | 652C5 | - | M5 | 652C5 | - | |
1.33 € | 1 | Available | 3 Days | Red | Copper silver plated | 10 mm² (max) | 10 | Partially insulated | 652C6 | - | M5 | 652C6 | - | |
1.53 € | 1 | Available | 3 Days | Blue | Copper silver plated | 16 mm² (max) | 16 | Partially insulated | 653C6 | - | M6 | 653C6 | - |
Loading...
Basic information
| Product type | U terminal |
|---|
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
