Panel feed-through, Q
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Part Number
|
|---|
| 1437274 |
| 1584787 |
| 1585045 |
| 1640634 |
| 1641497 |
| 1641659 |
| 1670277 |
| Part Number | Related to |
Standard Unit Price
| Minimum order quantity | Volume Discount | Contact material | Width (mm) | Height (mm) | Rated current (A) | Rated voltage (V) | Number of poles | Length (mm) | Rated surge voltage (kV) | Connection size thread | Pole codification | Colour coding/contact insert | Colour of the separate adapter piece | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
32.63 € | 6 | 40 Days | Other | 24 | 24 | 15 | 500 | 4 | 55.9 | 6 | M20 | - | Black | Black | |||
18.74 € | 10 | 26 Days | CuZn | 24 | 24 | 17.5 | 500 | 4 | 55.9 | 6 | M20 | - | Black | Black | |||
22.65 € | 10 | 26 Days | CuZn | 24 | 24 | 15 | 500 | 4 | 55.9 | 6 | M20 | - | Black | Black | |||
9.51 € | 20 | 26 Days | Other | 19 | 19 | 9 | 160 | 3 | 41.3 | 4 | M16 | 1, 2, 3 | Green | Other | |||
9.74 € | 20 | 26 Days | CuZn | 19 | 19 | 9 | 160 | 3 | 41.3 | 4 | M16 | 1, 2, 3 | Black | Black | |||
10.67 € | 20 | 26 Days | CuZn | 24 | 24 | 17.5 | 500 | 3 | 55.9 | 6 | M20 | 1, 2, 3 | Black | Black | |||
9.07 € | 30 | 98 Days | Other | 34.3 | 22.5 | 17.5 | 250 | 2 | 42.3 | 6 | - | 1, 2 | Green | Other |
Loading...
Basic information
| Model | - | Halogen free | false | Connection type | - |
|---|---|---|---|---|---|
| Colour housing | - | Locking mechanism | - | Material housing | Other |
| Surface finish contacts | Other | Pollution degree | - | Angle of plug | - |
| Mechanical coding | false | Continuity resistor(mOhm) | - | Angle of inclination(°) | -|- |
| Degree of protection (IP) | IP65 | Number of connections per pole | 1 | Fire load(kWh) | - |
| Built-in version | - | Connection cross section (fine-strand)(mm²) | -|- | Connection cross section (solid-core)(mm²) | -|- |
| Max. continuous temperature resistance contact part(°C) | - | Max. continuous temperature resistance strain relief(°C) | - | Length soldering pin(mm) | - |
| Wall thickness housing(mm) | - |
Configure
Basic Attributes
-
Contact material
-
Width(mm)
-
Height(mm)
-
Rated current(A)
-
Rated voltage(V)
-
Number of poles
-
Length(mm)
-
Rated surge voltage(kV)
-
Connection size thread
-
Pole codification
-
Colour coding/contact insert
-
Colour of the separate adapter piece
-
Type
Filter by standard shipping days
-
- All
- 26 Days or Less
- 40 Days or Less
- 98 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
