Type 2 / 3 surge protection device, PLT-SEC
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Part Number
|
|---|
| 2907918 |
| 2907927 |
| 2907928 |
| Part Number | Related to |
Standard Unit Price
| Minimum order quantity | Volume Discount | Voltage protection level (kV) | Max. continuous voltage AC (V) | Nominal voltage AC (V) | Voltage protection level L-N (kV) | Voltage protection level L-PE/N-PE (kV) | Max. continuous voltage DC (V) | |
|---|---|---|---|---|---|---|---|---|---|---|---|
128.70 € | 5 | 7 Days | 0.75 | 150 | 120 | 0.75 | 0.85 | 150 | |||
128.70 € | 5 | 7 Days | 0.75 | 150 | 120 | 0.75 | 0.85 | 150 | |||
128.70 € | 5 | 7 Days | 1.25 | 264 | 240 | 1.25 | 1.4 | 275 |
Loading...
Basic information
| Mounting method | DIN rail (top hat rail) 35 mm | With remote signalling contact | true | Number of poles | 2 |
|---|---|---|---|---|---|
| Total discharge current (8/20) (L+N-PE)(kA) | 5 | Nominal discharge surge current (8/20) (L-N)(kA) | 5 | Nominal load current(A) | 26 |
| Nominal voltage DC(V) | - | Category type 3 | true | Signalling at the device | Optic |
| Degree of protection (IP) | - | With interference suppressor filter | false | Max. conductor cross section solid (solid, stranded)(mm²) | 4 |
| Max. conductor cross section flexible (fine-strand)(mm²) | 2.5 | Total discharge current (8/20) (L1+L2+L3+N-PE)(kA) | - |
Configure
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
