Long Drawbar
Click on this image to zoom in.
Click on this image to zoom in.
Drawbar for auto chuck. Easy to attach and remove, and chucking accuracy is maintained through a floating mechanism.
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
3R-605.1
Basic information
| Product Type | Other Jigs | Dimensions 1 | φ20×57.1mm | Dimensions 2 | φ7 mm Equipped with jet holes |
|---|
This page is Long Drawbar, part number 3R-605.1.
You can find the detail information about specifications and dimensions on part number 3R-605.1.
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
