Rod End Bearings, Spherical Bearings DO2RS Series
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Product data
- CAD data not available
Part Number
|
|---|
| GAL60 DO2RS |
| GE90 DO2RS |
| GE200 DO2RS |
| GIL25 DO2RS |
| GIL30 DO2RS |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | I.D. D (mm) | Connection screw direction | Outer diameter (mm) | Width (mm) | Thread type | Weight (g) | |
|---|---|---|---|---|---|---|---|---|---|---|
149.10 € | 1 | 4 Days | 60 | Left Screw | 135 | 44 | Male thread | 5900.0 | ||
99,999.00 € | 1 | 4 Days | 90 | - | 130 | 60 | - | 2700.0 | ||
975.22 € | 1 | 4 Days | 200 | - | 290 | 130 | - | 28300.0 | ||
22.60 € | 1 | 4 Days | 25 | Left Screw | 64 | 126 | Female thread | 640.0 | ||
34.96 € | 1 | 4 Days | 30 | Left Screw | 73 | 146.5 | Female thread | 930.0 |
Loading...
Basic information
| Seal | Lip seal on both sides | Maintenance | Version requiring maintenance |
|---|
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
