INA Pillow Block Unit with Long Base, Gray Cast Iron, Grub Screws in Inner Ring, R Seal
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Part Number
|
|---|
| 0008582850000 |
| 0008582930000 |
| 0008583070000 |
| 0008583150000 |
| 0008583230000 |
| 0008720910000 |
| 0009475710000 |
| 0009477680000 |
| 0009481440000 |
| 0009481520000 |
| 0009595960000 |
| 0009733000000 |
| 0009733190000 |
| Part Number | Related to |
Standard Unit Price
| Minimum order quantity | Volume Discount | Shaft Bore Dia. d (mm) | Basic Load Rating, Dynamic Rating (N) | Basic Load Rating, Static Rating (N) | Housing | Customs tariff weight (kg) | Unit height H (mm) | Center hole distance J (mm) | Unit code | S1 (mm) | H2 (mm) | Unit width A (mm) | N1 (mm) | Unit length L (mm) | A1 (mm) | Base height to shaft center H1/L1 (mm) | Bearing code | Protection cap | B (mm) | Width/diameter of fixing hole N (mm) | Product code | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
- | 1 | 5 Days | 20 | 12800 | 6600 | ASE04 | 0.58 | 64 | 333 | GYE20-KRR-B | 18.3 | 12.8 | 11 | 19 | 130 | 19 | 64 | GG.ASE04-E-N | KASK04 | 31 | 19 | RASEY20-XL-N | |||
- | 1 | 5 Days | 25 | 14000 | 7800 | ASE05 | 0.7 | 70 | 365 | GYE25-KRR-B | 19.6 | 14 | 11 | 19 | 130 | 21 | 70 | GG.ASE05-N | KASK05 | 34.1 | 19 | RASEY25-XL-N | |||
- | 1 | 5 Days | 35 | 25500 | 15300 | ASE07 | 1.55 | 93 | 476 | GYE35-KRR-B | 25.4 | 25.5 | 14 | 21 | 163 | 27 | 93 | GG.ASE07-N | KASK07 | 42.9 | 21 | RASEY35-XL-N | |||
- | 1 | 5 Days | 40 | 32500 | 19800 | ASE08 | 1.84 | 99 | 492 | GYE40-KRR-B | 30.2 | 32.5 | 14 | 26 | 179 | 30 | 99 | GG.ASE/AK08-N | KASK08 | 49.2 | 26 | RASEY40-XL-N | |||
- | 1 | 5 Days | 50 | 35000 | 23200 | ASE10 | 2.62 | 115 | 572 | GYE50-KRR-B | 32.6 | 35 | 18 | 23 | 200 | 34 | 115 | GG.ASE10-N | KASK10 | 51.6 | 23 | RASEY50-XL-N | |||
32.32 € | 1 | Quote | 30 | 19500 | 11300 | ASE06 | 1.13 | 82 | 429 | GYE30-KRR-B | 22.2 | 19.5 | 14 | 22 | 158 | 25 | 82 | GG.ASE06-N | KASK06 | 38.1 | 22 | RASEY30-XL-N | |||
76.74 € | 1 | Quote | 55 | 43500 | 29000 | ASE11 | 3.22 | 124.5 | 635 | GYE55-KRR-B | 33.4 | 43.5 | 18 | 30 | 222 | 35 | 124.50 | GG.ASE11 | - | 55.6 | 30 | RASEY55-XL | |||
- | 1 | 5 Days | 60 | 52000 | 36000 | ASE12 | 4.44 | 140 | 699 | GYE60-KRR-B | 39.7 | 52 | 18 | 28 | 240 | 42 | 140 | GG.ASE12-N | KASK12 | 65.1 | 28 | RASEY60-XL-N | |||
- | 1 | 5 Days | 70 | 62000 | 44000 | ASE14 | 5.93 | 156 | 794 | GYE70-KRR-B | 44.4 | 62 | 22 | 28 | 260 | 44 | 156 | GG.ASE14 | - | 74.6 | 28 | RASEY70-XL | |||
- | 1 | 5 Days | 75 | 62000 | 44500 | ASE15 | 6.5 | 164 | 825 | GYE75-KRR-B | 44.5 | 62 | 22 | 30 | 265 | 48 | 164 | GG.ASE15 | - | 77.8 | 30 | RASEY75-XL | |||
- | 1 | 5 Days | 80 | 72000 | 54000 | ASE16 | 8.41 | 175 | 89 | GYE80-KRR-B | 49.3 | 72 | 26 | 35 | 290 | 55 | 175 | GG.ASE16 | - | 82.6 | 35 | RASEY80-XL | |||
- | 1 | 5 Days | 12 | 9800 | 4750 | ASE03 | 0.43 | 57 | 302 | GYE12-KRR-B | 15.9 | 9.8 | 11 | 19 | 125 | 18 | 57 | GG.ASE03 | - | 27.4 | 19 | RASEY12-XL | |||
23.60 € | 1 | Quote | 15 | 9800 | 4750 | ASE03 | 0.42 | 57 | 302 | GYE15-KRR-B | 15.9 | 9.8 | 11 | 19 | 125 | 18 | 57 | GG.ASE03 | - | 27.4 | 19 | RASEY15-XL |
Loading...
Basic information
| Bearing Unit, Type | Pillow Type | Unit Body Material | Cast Iron | Customs tariff goods number | 84832000 |
|---|---|---|---|---|---|
| Method of fixing | Grub screw | Number of fixing holes | 2 | Customs tariff weight unit | kg |
| Hole shape | cylindrical | Unit material | Gray cast iron | Model | cylindrical |
| Model series | RASEY.. | Thread | M6 | Lubrication hole Q | M6 |
| Relubrication possible yes/no | yes | Customs tariff weight per | 1 | Customs tariff country of origin | DE |
Configure
Basic Attributes
-
Shaft Bore Dia. d(mm)
-
Housing
-
Customs tariff weight(kg)
-
Unit height H(mm)
-
Center hole distance J(mm)
-
Unit code
-
S1(mm)
-
H2(mm)
-
Unit width A(mm)
-
N1(mm)
-
Unit length L(mm)
-
A1(mm)
-
Base height to shaft center H1/L1(mm)
-
Bearing code
-
Protection cap
-
B(mm)
-
Width/diameter of fixing hole N(mm)
-
Type
-
Filter by CAD data type
- 3D
Filter by standard shipping days
-
- All
- 5 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
