Simple Flocon FK Series Female Screw Type
- Volume Discount
- Stock
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Part Number
|
|---|
| FK-M3 |
| FK-M4 |
| FK-M5 |
| FK-M6 |
| FK-M8X1.0 |
| FK-M8X1.25 |
| FK-M10 |
| FK-M12 |
| FK-M14 |
| FK-M16 |
| FK-M18 |
| FK-M22 |
| FK-M26 |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Connecting Thread Nominal M (mm) | Connecting Thread Nominal P (mm) | Maximum Applied Tensile / Compression Force (kN) | Allowable Eccentricity U (mm) | Nominal Diameter of Thread of X Pitch | |
|---|---|---|---|---|---|---|---|---|---|
16.00 € | 1 | 11 Days | M3～M8 | 0.5–0.8 | 0.063 | 0.3 | M3X0.5 | ||
16.00 € | 1 | 11 Days | M3～M8 | 0.5–0.8 | 0.11 | 0.3 | M4X0.7 | ||
16.68 € | 1 | Available | 6 Days | M3～M8 | 0.5–0.8 | 0.179 | 0.3 | M5X0.8 | |
24.40 € | 1 | 11 Days | M3～M8 | 1~1.75 | 0.253 | 0.3 | M6X1.0 | ||
24.40 € | 1 | 11 Days | M3～M8 | 1~1.75 | 0.462 | 0.3 | M8X1.0 | ||
24.40 € | 1 | Available | 6 Days | M3～M8 | 1~1.75 | 0.462 | 0.3 | M8X1.25 | |
25.09 € | 1 | Available | 12 Days | M10～M18 | 1~1.75 | 0.734 | 0.3 | M10X1.25 | |
26.97 € | 1 | 11 Days | M10～M18 | 1~1.75 | 1.069 | 0.3 | M12X1.5 | ||
33.49 € | 1 | Available | 6 Days | M10～M18 | 1~1.75 | 1.466 | 0.3 | M14X1.5 | |
35.20 € | 1 | 11 Days | M10～M18 | 1~1.75 | 2.003 | 0.7 | M16X1.5 | ||
38.45 € | 1 | Available | 6 Days | M10～M18 | 1~1.75 | 2.448 | 0.7 | M18X1.5 | |
41.53 € | 1 | 11 Days | M20～M26 | 1~1.75 | 3.896 | 0.7 | M22X1.5 | ||
54.98 € | 1 | Available |
Same day
Stock | M20～M26 | 1~1.75 | 6.219 | 0.7 | M26X1.5 |
Loading...
Basic information
| Type | Cylinder Connector | Cylinder Used | Air pressure cylinders | Connection Type, Cylinder Side | Female Thread |
|---|---|---|---|---|---|
| Cylinder Connector Details | Set | Case | Steel (nickel plating) | Mounting | Flange Shape |
| Ball Stud | Steel (nickel plating) |
Configure
Stock
-
- Show only stock items
Basic Attributes
-
Connecting Thread Nominal M(mm)
-
Connecting Thread Nominal P(mm)
- 0.5–0.8
- 1~1.75
-
Allowable Eccentricity U(mm)
-
Nominal Diameter of Thread of X Pitch
-
Type
- FK
-
Filter by CAD data type
- 2D
- 3D
Filter by standard shipping days
-
- All
- Same day
- 6 Days or Less
- 11 Days or Less
- 12 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
