Vacuum Pad, Bellows Type, VPF

Vacuum Pad, Bellows Type, VPF

Ideal for transporting bags containing sealed pouches and foodstuffs. *CAD data currently being revised for this series. This will be available as soon as modifications are complete

[Features]
· Absorbs extremely soft media such as paper and vinyl, and has a swing pad feature.
· A wide range of pad sizes, pad materials, and holder shapes are available.
· Downsizes holders (A and B types) for existing vacuum pads, saving space.
· The pad section can be changed without removing the holder from the equipment, as is conventional.
· Also compatible with the optional fall prevention valve and pad direct attachment type filter.
· Suitable for applications requiring copper-based metal not to be used and as part of efforts to reduce ozone concentrations.

Part Number

Once your search is narrowed to one product,
the corresponding part number is displayed here.

Part Number
VPF10BN
VPF10BS
VPF10BSE
VPF20BN
VPF20BS
VPF20BSE
VPF30BN
VPF30BS
VPF30BSE
VPF40BN
VPF40BS
VPF40BSE
VPF50BN
VPF50BS
VPF50BSE
Part NumberStandard Unit PriceVolume DiscountShipping Days?RoHSRubber Group Material Environment Color Outer Diameter D
(φ)
Height L1
(mm)
Full length B
(mm)

23.40 €

9 Days -[Nitrile Rubber] Nitrile RubberStandardBlack101659

24.79 €

9 Days 10[Silicon Rubber] Silicone RubberStandard[White] White101659

24.79 €

9 Days -[Silicon Rubber] Silicone Rubber +CarbonStandard / Static electricity diffusionBlack101659

24.17 €

9 Days -[Nitrile Rubber] Nitrile RubberStandardBlack201963

25.74 €

9 Days -[Silicon Rubber] Silicone RubberStandard[White] White201963

25.75 €

9 Days -[Silicon Rubber] Silicone Rubber +CarbonStandard / Static electricity diffusionBlack201963

25.44 €

9 Days -[Nitrile Rubber] Nitrile RubberStandardBlack302367

27.02 €

9 Days -[Silicon Rubber] Silicone RubberStandard[White] White302367

27.33 €

9 Days -[Silicon Rubber] Silicone Rubber +CarbonStandard / Static electricity diffusionBlack302367

28.32 €

9 Days -[Nitrile Rubber] Nitrile RubberStandardBlack403074

30.21 €

9 Days -[Silicon Rubber] Silicone RubberStandard[White] White403074

30.84 €

9 Days -[Silicon Rubber] Silicone Rubber +CarbonStandard / Static electricity diffusionBlack403074

33.07 €

9 Days -[Nitrile Rubber] Nitrile RubberStandardBlack503276

35.26 €

9 Days -[Silicon Rubber] Silicone RubberStandard[White] White503276

36.51 €

9 Days -[Silicon Rubber] Silicone Rubber +CarbonStandard / Static electricity diffusionBlack503276

Loading...

  1. 1

Basic information

Pad Type Standard / Ribbed / Holder Set Pad Type Bellows Mounting Method Pad Screw Fixed
Material Rubber-Based Mounting Bracket Spring Type Springs Power(N) 7.9~15.0
Stroke(mm) 5.8 Vacuum Outlet Direction Top Mount Connection Screw M14×1
Vacuum Outlet Screw M14×1 Fall Prevention Valve None Direct Attached Filter None
Swiveling angle No Swiveling
