Tube Fitting Union Elbow for General Piping
- Promotional pricing ends 30/11/2024
- Volume Discount
· One-touch fitting for general pneumatic pipes.
· Various products available.
· Can change the take-off angle of the resin body after mounting.
· Centralized piping is enabled.
· Light gray types, and clean room packaged types optionally available.
· Clean room packaging specifications define the use of fluorinated grease.
· After purification with clean air, the item is package in an ISO Class 6-equivalent clean room that has been purified with clean air.
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Part Number
|
|---|
| PV1/4 |
| PV1/4W |
| PV3/8 |
| PV4 |
| PV4C |
| PV4W |
| PV5/16 |
| PV6 |
| PV6C |
| PV6W |
| PV8 |
| PV8W |
| PV10 |
| PV10C |
| PV10W |
| PV12 |
| PV12C |
| PV12W |
| PV16 |
| PV16W |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | RoHS | Application | Compatible Tube Outer Diameter 1 (mm) | Package Specifications | Release Ring Color | Resin Body Color | |
|---|---|---|---|---|---|---|---|---|---|---|
5.87 € 4.11 € | 1 | Available |
Same day
Stock | - | Standard/Mini | 6.35 | Regular Packaging Specifications | White | Black | |
3.19 € | 10 | 11 Days | - | Standard/Mini | 6.35 | Regular Packaging Specifications | White | Light Gray | ||
5.63 € 3.94 € | 1 |
Same day
Stock | - | Standard/Mini | 9.53 | Regular Packaging Specifications | White | Black | ||
2.96 € | 10 | 5 Days | 10 | Standard/Mini | 4 | Regular Packaging Specifications | Black | Black | ||
4.24 € 2.97 € | 1 |
Same day
Stock | - | Standard/Mini / Clean circumstance | 4 | Clean Room Packaging Specifications | Light blue | Light Gray | ||
3.08 € 2.16 € | 1 |
Same day
Stock | - | Standard/Mini | 4 | Regular Packaging Specifications | Light Gray | Light Gray | ||
4.23 € | 10 | 11 Days | - | Standard/Mini | 7.94 | Regular Packaging Specifications | White | Black | ||
3.16 € | 10 | 5 Days | 10 | Standard/Mini | 6 | Regular Packaging Specifications | Black | Black | ||
5.65 € 3.96 € | 1 | Available |
Same day
Stock | - | Standard/Mini / Clean circumstance | 6 | Clean Room Packaging Specifications | Light blue | Light Gray | |
3.99 € 2.79 € | 1 | Available |
Same day
Stock | - | Standard/Mini | 6 | Regular Packaging Specifications | Light Gray | Light Gray | |
4.04 € 2.83 € | 1 | Available |
Same day
Stock | 10 | Standard/Mini | 8 | Regular Packaging Specifications | Black | Black | |
4.23 € | 10 | Available | 5 Days | - | Standard/Mini | 8 | Regular Packaging Specifications | Light Gray | Light Gray | |
4.79 € | 10 | 5 Days | 10 | Standard/Mini | 10 | Regular Packaging Specifications | Black | Black | ||
7.48 € 5.24 € | 1 |
Same day
Stock | - | Standard/Mini / Clean circumstance | 10 | Clean Room Packaging Specifications | Light blue | Light Gray | ||
5.63 € 3.94 € | 1 |
Same day
Stock | - | Standard/Mini | 10 | Regular Packaging Specifications | Light Gray | Light Gray | ||
5.21 € | 10 | 5 Days | 10 | Standard/Mini | 12 | Regular Packaging Specifications | Black | Black | ||
8.48 € 5.94 € | 1 |
Same day
Stock | - | Standard/Mini / Clean circumstance | 12 | Clean Room Packaging Specifications | Light blue | Light Gray | ||
6.91 € | 10 | 11 Days | - | Standard/Mini | 12 | Regular Packaging Specifications | Light Gray | Light Gray | ||
7.64 € 5.35 € | 1 |
Same day
Stock | 10 | Standard/Mini | 16 | Regular Packaging Specifications | Black | Black | ||
10.40 € | 10 | 11 Days | - | Standard/Mini | 16 | Regular Packaging Specifications | Light Gray | Light Gray |
Loading...
Basic information
| Type | Single-Action Coupling | Fitting Type | Union with same diameter | Applicable Fluid | Water / Air |
|---|---|---|---|---|---|
| Union: Same Diameter | Union Elbow | Operating Temperature(°C) | 0::60 |
