Oval Grip (Self Locking) (OG)
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | RoHS | Grip Material | Mounting Method | Nominal of Thread | Shaft Insertion Hole Diameter d (mm) | Grip thickness D (mm) | Grip length (mm) | Color | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
3.55 € | 1 | 6 Days | 10 | Phenol | Press Fit | - | 6 | 15 | 25 | - | ||
2.35 € | 1 | 6 Days | 10 | [Polyamide] Polyamide | Female Thread | M6 | - | 16 | 25 | - | ||
3.11 € | 1 | 6 Days | 10 | [Polyamide] Polyamide | Press Fit | - | 6 | 16 | 25 | BR (Black) | ||
3.75 € | 1 | 6 Days | 10 | [Polyamide] Polyamide | Press Fit | - | 6 | 16 | 25 | CL (White) | ||
3.42 € | 1 | 8 Days | 10 | [Polyamide] Polyamide | Press Fit | - | 6 | 16 | 25 | RE (Red) | ||
3.98 € | 1 | 6 Days | 10 | Phenol | Press Fit | - | 8 | 20 | 31 | - | ||
2.71 € | 1 | 6 Days | 10 | [Polyamide] Polyamide | Female Thread | M8 | - | 20 | 32 | - | ||
3.44 € | 1 | 6 Days | 10 | [Polyamide] Polyamide | Press Fit | - | 8 | 20 | 32 | BR (Black) | ||
4.09 € | 1 | 10 Days | 10 | [Polyamide] Polyamide | Press Fit | - | 8 | 20 | 32 | CL (White) | ||
3.66 € | 1 | 6 Days | 10 | [Polyamide] Polyamide | Press Fit | - | 8 | 20 | 32 | RE (Red) | ||
5.01 € | 1 | 6 Days | 10 | Phenol | Press Fit | - | 10 | 26 | 42 | - | ||
3.63 € | 1 | 6 Days | 10 | [Polyamide] Polyamide | Female Thread | M10 | - | 26 | 42 | - | ||
3.64 € | 1 | 6 Days | 10 | [Polyamide] Polyamide | Female Thread | M8 | - | 26 | 42 | - | ||
3.81 € | 1 | 6 Days | 10 | [Polyamide] Polyamide | Press Fit | - | 10 | 26 | 42 | BR (Black) | ||
4.67 € | 1 | 10 Days | 10 | [Polyamide] Polyamide | Press Fit | - | 10 | 26 | 42 | CL (White) | ||
4.03 € | 1 | 6 Days | 10 | [Polyamide] Polyamide | Press Fit | - | 10 | 26 | 42 | RE (Red) | ||
3.83 € | 1 | 6 Days | 10 | [Polyamide] Polyamide | Press Fit | - | 8 | 26 | 42 | BR (Black) | ||
4.03 € | 1 | 8 Days | 10 | [Polyamide] Polyamide | Press Fit | - | 8 | 26 | 42 | RE (Red) | ||
6.57 € | 1 | 6 Days | 10 | Phenol | Press Fit | - | 12 | 33 | 54 | - | ||
5.12 € | 1 | 6 Days | 10 | [Polyamide] Polyamide | Female Thread | M12 | - | 34 | 54.5 | - | ||
5.14 € | 1 | 6 Days | 10 | [Polyamide] Polyamide | Female Thread | M10 | - | 34 | 54.5 | - | ||
5.77 € | 1 | 6 Days | 10 | [Polyamide] Polyamide | Press Fit | - | 12 | 34 | 54.5 | BR (Black) | ||
6.32 € | 1 | 10 Days | 10 | [Polyamide] Polyamide | Press Fit | - | 12 | 34 | 54.5 | CL (White) | ||
6.43 € | 1 | 6 Days | 10 | [Polyamide] Polyamide | Press Fit | - | 12 | 34 | 54.5 | RE (Red) | ||
5.79 € | 1 | 6 Days | 10 | [Polyamide] Polyamide | Press Fit | - | 10 | 34 | 54.5 | BR (Black) | ||
6.33 € | 1 | 10 Days | 10 | [Polyamide] Polyamide | Press Fit | - | 10 | 34 | 54.5 | CL (White) | ||
6.44 € | 1 | 6 Days | 10 | [Polyamide] Polyamide | Press Fit | - | 10 | 34 | 54.5 | RE (Red) | ||
9.43 € | 1 | 6 Days | 10 | Phenol | Press Fit | - | 14 | 38 | 68 | - | ||
14.07 € | 1 | 6 Days | 10 | Phenol | Press Fit | - | 16 | 41 | 87 | - |
