POP Shield Type Rivet AK【1-1,000 Pieces Per Package】
- Volume Discount
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Product data
- CAD data not available
Part Number
|
|---|
| AK42 |
| AK43 |
| AK44 |
| AK45 |
| AK52 |
| AK53 |
| AK54 |
| AK62 |
| AK63 |
| AK64 |
| AK65 |
| AK66 |
| AK68 |
| Part Number |
Standard Unit Price
| Number of pc(s). included in pkg. | Minimum order quantity | Volume Discount | RoHS | Nominal (mm) | Recommended Fastening Plate Thickness (mm) | Length L1 (mm) | Sales Unit | |
|---|---|---|---|---|---|---|---|---|---|---|
126.93 € | 1,000 Pieces Per Package | 1 pack | 6 Days | 10 | 3.2 | 1.6~3.2 | 8.6 | Box/Package | ||
130.05 € | 1,000 Pieces Per Package | 1 pack | 6 Days | 10 | 3.2 | 3.2~4.8 | 10.2 | Box/Package | ||
146.31 € | 1,000 Pieces Per Package | 1 pack | 6 Days | 10 | 3.2 | 4.8–6.4 | 11.8 | Box/Package | ||
162.86 € | 1,000 Pieces Per Package | 1 pack | 6 Days | 10 | 3.2 | 6.4~8.0 | 13.4 | Box/Package | ||
1.33 € | 1 | Available | 6 Days | 10 | 4.0 | 2.2~3.2 | 9.4 | Box/Package | ||
178.98 € | 1,000 Pieces Per Package | 1 pack | 6 Days | 10 | 4.0 | 3.2~4.8 | 11.0 | Box/Package | ||
208.49 € | 1,000 Pieces Per Package | 1 pack | 6 Days | 10 | 4.0 | 4.8–6.4 | 12.6 | Box/Package | ||
133.33 € | 1,000 Pieces Per Package | 1 pack | 6 Days | 10 | 4.8 | 2.5~3.2 | 10.1 | Box/Package | ||
136.91 € | 1,000 Pieces Per Package | 1 pack | 6 Days | 10 | 4.8 | 3.2~4.8 | 11.7 | Box/Package | ||
0.25 € | 1 | Available | 6 Days | 10 | 4.8 | 4.8–6.4 | 13.2 | Low Quantity (can be purchased from one) | ||
138.25 € | 1,000 Pieces Per Package | 1 pack | 6 Days | 10 | 4.8 | 6.4~8.0 | 14.8 | Box/Package | ||
140.04 € | 1,000 Pieces Per Package | 1 pack | 6 Days | 10 | 4.8 | 8.0~9.6 | 16.4 | Box/Package | ||
405.36 € | 1,000 Pieces Per Package | 1 pack | 6 Days | 10 | 4.8 | 9.6~12.8 | 19.6 | Box/Package |
Loading...
Basic information
| Material | Iron | Surface Treatment | NA | Details of Surface Treatment | NA |
|---|---|---|---|---|---|
| Shape of The Head | Countersunk Head |
Configure
Basic Attributes
-
Nominal(mm)
- 3.2
- 4.0
- 4.8
-
Recommended Fastening Plate Thickness(mm)
- 1.6~3.2
- 2.2~3.2
- 2.5~3.2
- 3.2~4.8
- 4.8–6.4
- 6.4~8.0
- 8.0~9.6
- 9.6~12.8
-
Length L1(mm)
-
Sales Unit
- Box/Package
- Low Quantity (can be purchased from one)
-
Type
- AK
Filter by standard shipping days
-
- All
- 6 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
