Clear Sheet with Flameproof Threading
· Does not produce dioxins when incinerated.
· The included threading provides improved strength while still maintaining a high level of transparency for the overall sheet.
· A fireproofed article as stipulated in the Fire Service Law. (Flameproof Class 2)
· A chain is included in the bottom section.
Applications
· A partitioning curtain for factories and work sites.
· Windbreak sheeting.
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Product data
- CAD data not available
Part Number
|
|---|
| TCI0203 |
| TCI0204 |
| TCI0403 |
| TCI0404 |
| TCI0603 |
| TCI0604 |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Width (mm) | Length (m) | Grommet pitch (mm) | Number of Grommets (piece) | JAN Code | Order Code | Mass (kg) | |
|---|---|---|---|---|---|---|---|---|---|---|---|
147.92 € | 1 | 6 Days | 2000 | 3 | 280×500 | 20 | 4989999173277 | 276-8631 | 2.2 | ||
191.92 € | 1 | 6 Days | 2000 | 4 | 280×500 | 24 | 4989999173307 | 276-8666 | 2.6 | ||
278.21 € | 1 | 6 Days | 4000 | 3 | 300×500 | 26 | 4989999173284 | 276-8640 | 4.4 | ||
367.15 € | 1 | 6 Days | 4000 | 4 | 300×500 | 30 | 4989999173314 | 276-8674 | 5.2 | ||
440.80 € | 1 | 6 Days | 6000 | 3 | 300×500 | 33 | 4989999173291 | 276-8658 | 6.5 | ||
550.68 € | 1 | 6 Days | 6000 | 4 | 300×500 | 37 | 4989999173321 | 276-8682 | 7.8 |
Loading...
Basic information
| Type | Curtains | Material (Sheet) | Polypropylene (PP) | Material (Grommet) | Brass |
|---|---|---|---|---|---|
| Material (Chain) | Steel | Color | Clear | Thickness(mm) | 0.45 |
| Grommet Inner Diameter(mm) | 12 | Tensile Strength(N) | Length: 575 / Width: 520 | Extensibility(%) | Length: 23 / Width: 22 |
| Rupture Extensibility(N) | Length: 195 / Width: 186 | Weight(g/m3) | 220 | Specifications | Fire Protection (2 Types of Protection) |
| Number Contained In A Packet(sheet) | 1 |
Configure
Basic Attributes
-
Width(mm)
- 2000
- 4000
- 6000
-
Length(m)
- 3
- 4
-
Grommet pitch(mm)
- 280×500
- 300×500
-
Number of Grommets(piece)
- 20
- 24
- 26
- 30
- 33
- 37
-
JAN Code
- 4989999173277
- 4989999173284
- 4989999173291
- 4989999173307
- 4989999173314
- 4989999173321
-
Order Code
- 276-8682
- 276-8674
- 276-8666
- 276-8658
- 276-8640
- 276-8631
-
Type
- TCI
Filter by standard shipping days
-
- All
- 6 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
