Pressure sensor, SPAE Series
Click on this image to zoom in.
Click on this image to zoom in.
- Volume Discount
・Operating medium: Compressed air as per ISO 8573-1:2010 [7:4:4]
・Corrosion resistance class (CRC): 2 - Moderate corrosion stress
・Protection Rating: IP40
[Features]
・Electronic pressure sensor with piezoresistive pressure measuring cell, integrated signal processing, numeric pressure indicator in percent, operating key and a switching output, PNP/NPN switchable
・Display of minimum and maximum measured value
・All parameters entered can be transferred to other SPAEs (replicating function)
・Communication interface IO-Link
・The extremely small, extremely light, extremely convenient pressure transmitter SPAE monitors the pressure level of filtered compressed air from −1 … 0 and 0 … 10 bar. Ideal for vacuum monitoring with pick & place or for pressure monitoring in pneumatic applications
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Product data
- CAD data not available
| Part Number | Related to |
Standard Unit Price
| Minimum order quantity | Volume Discount | Pneumatic connection | Pressure measuring range initial value (bar) | Pressure measuring range end value (bar) | Max. overload pressure (bar) | Manufacturer part # | |
|---|---|---|---|---|---|---|---|---|---|---|
119.05 € | 1 | Available | 10 Days | Cartridge 10 mm | -1 | 1 | 5 | 8025979 | ||
86.32 € | 1 | 4 Days | Flange | 0 | 10 | 15 | 8001449 | |||
88.46 € | 1 | 4 Days | QS-3 | 0 | 10 | 15 | 8001447 | |||
88.46 € | 1 | 3 Days | QS-4 | 0 | 10 | 15 | 8001448 | |||
84.18 € | 1 | 4 Days | Push-in sleeve QS-4 | 0 | 10 | 15 | 8001445 | |||
84.18 € | 1 | 4 Days | Push-in sleeve QS-6 | 0 | 10 | 15 | 8001446 | |||
86.32 € | 1 | 4 Days | Flange | 0 | -1 | 5 | 8001444 | |||
96.08 € | 1 | 4 Days | Cartridge 10 mm | 0 | -1 | 5 | 8025978 | |||
88.46 € | 1 | 4 Days | QS-3 | 0 | -1 | 5 | 8001442 | |||
88.46 € | 1 | 4 Days | QS-4 | 0 | -1 | 5 | 8001443 | |||
84.18 € | 1 | 3 Days | Push-in sleeve QS-4 | 0 | -1 | 5 | 8001440 | |||
84.18 € | 1 | 4 Days | Push-in sleeve QS-6 | 0 | -1 | 5 | 8001441 |
Loading...
Basic information
| Operating Temperature Range(℃) | 0::50 | Protection Rating | IP40 | Housing material | PA-reinforced |
|---|---|---|---|---|---|
| Display type | LED display, 2-digit | Switching output | PNP/NPN switchable | Switching element function | N/C contact, N/O contact, Switchable |
| Max. output current(mA) | 100 | Min. Temperature of medium(°C) | 0 | Max. Temperature of medium(°C) | 50 |
| IP rating | IP40 | DC operating voltage range(V) | 18-30 | Repetition accuracy in ± %FS | 0.3 %FS |
| Operating medium | Compressed air as per ISO 8573-1:2010 [7:4:4] | Corrosion resistance class (CRC) | 2 - Moderate corrosion stress | Weight(g) | 40 |
Configure
Basic Attributes
-
Pneumatic connection
-
Pressure measuring range initial value(bar)
- -1
- 0
-
Pressure measuring range end value(bar)
- -1
- 1
- 10
-
Max. overload pressure(bar)
Filter by standard shipping days
-
- All
- 3 Days or Less
- 4 Days or Less
- 10 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
