Soft start valve, MS4 Series
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Product data
- CAD data not available
Part Number
|
|---|
| MS4-DE-1/4-V110 |
| MS4-DE-1/4-V230 |
| MS4-DL-1/4 |
| MS4-DL-1/4-Z |
| MS4-DL-1/8 |
| Part Number | Related to |
Standard Unit Price
| Minimum order quantity | Volume Discount | Actuation type | Standard nominal flow rate (l/min) | Pneumatic connection 1 | Pneumatic connection 2 | Degree of protection | C value (l/sbar) | b-value | Manufacturer part # | Weight (g) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
168.23 € | 1 | 22 Days | Electrical | 2000 | G1/4 | G1/4 | IP65 | 9.6 | 0.45 | 529519 | 263 | |||
168.23 € | 1 | 22 Days | Electrical | 2000 | G1/4 | G1/4 | IP65 | 9.6 | 0.45 | 529521 | 263 | |||
66.80 € | 1 | 3 Days | Pneumatic | 2000 | G1/4 | G1/4 | - | 9.6 | 0.45 | 529531 | 213 | |||
66.80 € | 1 | 4 Days | Pneumatic | 2000 | G1/4 | G1/4 | - | 9.6 | 0.45 | 529532 | 213 | |||
66.80 € | 1 | 4 Days | Pneumatic | 1000 | G1/8 | G1/8 | - | 4.6 | 0.5 | 529533 | 213 |
Loading...
Basic information
| Valve function | 2/2 | Housing material | Die-cast aluminum | Seals material | NBR |
|---|---|---|---|---|---|
| Reset method | Mechanical spring | Min. Operating pressure(bar) | 4 | Max. Operating pressure(bar) | 14 |
| Min. Temperature of medium(°C) | -10 | Max. Temperature of medium(°C) | 60 | Min. Ambient temperature(°C) | -10 |
| Max. Ambient temperature(°C) | 60 | Operating medium | Compressed air as per ISO 8573-1:2010 [7:4:4] Inert gas |
Corrosion resistance class (CRC) | 2 - Moderate corrosion stress |
Configure
Basic Attributes
-
Actuation type
- Electrical
- Pneumatic
-
Standard nominal flow rate(l/min)
-
Pneumatic connection 1
- G1/4
- G1/8
-
Pneumatic connection 2
- G1/4
- G1/8
-
Degree of protection
- IP65
-
C value(l/sbar)
-
b-value
Filter by standard shipping days
-
- All
- 3 Days or Less
- 4 Days or Less
- 22 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
