Proximity sensor, SIES Series
Click on this image to zoom in.
Click on this image to zoom in.
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Product data
- CAD data not available
Part Number
|
|---|
| SIES-Q40B-PA-X-2L |
| SIES-QB-PO-K-L |
| SIES-QB-PS-K-L |
| SIES-V3B-NS-S-L |
| SIES-V3B-PS-S-L |
| Part Number | Related to |
Standard Unit Price
| Minimum order quantity | Volume Discount | Housing material | Degree of protection | Cable length (m) | Material of cable sheath | Max. switching frequency (Hz) | Max. switching frequency DC (Hz) | Size | Rated operating distance (mm) | Electrical output | Switching output | Electrical connection | Repetition accuracy (mm) | Weight (g) | Manufacturer part # | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
86.29 € | 1 | 4 Days | PET | IP65 | - | - | 100 | 100 | 40x40x120 mm | 15 | PNP | PNP | Screw terminal | 0.75 | 230 | 150492 | |||
67.31 € | 1 | Quote | PBT-reinforced | IP67 | 2.5 | TPE-U(PUR) | 1200 | 1200 | 12x26x40 mm | 2 | NPN | PNP | 3-wire, Cable | 0.1 | 170 | 150489 | |||
67.31 € | 1 | Quote | PBT-reinforced | IP67 | 2.5 | TPE-U(PUR) | 1200 | 1200 | 12x26x40 mm | 2 | PNP | PNP | Cable, M8x1 | 0.1 | 170 | 150488 | |||
67.69 € | 1 | 4 Days | Die-cast zinc | IP67 | - | - | 1200 | 1200 | 15x20x30 mm | 2 | NPN | NPN | 3-pin, M8x1, Plug | 0.1 | 120 | 150490 | |||
64.80 € | 1 | 4 Days | Die-cast zinc | IP67 | - | - | 1200 | 1200 | 15x20x30 mm | 2 | PNP | PNP | 3-pin, M8x1, Plug | 0.1 | 120 | 150491 |
Loading...
Basic information
| DC operating voltage range(V) | 10-30 | Type of mounting | With through-hole | Mounting type | Flush |
|---|---|---|---|---|---|
| Min. Ambient temperature(°C) | -25 | Max. Ambient temperature(°C) | 85 |
Configure
Basic Attributes
-
Housing material
-
Degree of protection
-
Cable length(m)
-
Material of cable sheath
- TPE-U(PUR)
-
Max. switching frequency(Hz)
-
Max. switching frequency DC(Hz)
-
Size
-
Rated operating distance(mm)
-
Electrical output
- NPN
- PNP
-
Switching output
-
Electrical connection
-
Repetition accuracy(mm)
Filter by standard shipping days
-
- All
- 4 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
