Position sensor, SRBS Series
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Product data
- CAD data not available
| Part Number | Related to |
Standard Unit Price
| Minimum order quantity | Volume Discount | Weight (g) | Manufacturer part # | |
|---|---|---|---|---|---|---|---|
89.02 € | 1 | 4 Days | 35 | 2412001 | |||
77.71 € | 1 | 4 Days | 25 | 2619969 | |||
80.52 € | 1 | 4 Days | 30 | 2619972 | |||
89.02 € | 1 | 4 Days | 42 | 2393546 | |||
97.49 € | 1 | 3 Days | 55 | 2393547 | |||
104.55 € | 1 | 3 Days | 60 | 2393548 | |||
111.62 € | 1 | 4 Days | 81 | 2393549 | |||
120.11 € | 1 | 4 Days | 120 | 2393550 |
Loading...
Basic information
| Design | Round | Measuring principle | Magnetic Hall | Housing material | PA-reinforced, Polyester |
|---|---|---|---|---|---|
| Degree of protection | IP65, IP68 | DC operating voltage range(V) | 10-30 | Max. output current(mA) | 50 |
| Type of mounting | Screwed tightly | Mounting position | Any | Cable length(m) | 0.3 |
| Material of cable sheath | TPE-U(PUR) | Max. switching frequency(Hz) | 125 | Max. switching capacity DC(W) | 1.5 |
| Switching output | 2 x PNP or 2 x NPN switchable | Min. Ambient temperature(°C) | -20 | Max. Ambient temperature(°C) | 70 |
| Corrosion resistance class (CRC) | 2 - Moderate corrosion stress |
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
