Short-stroke cylinder, ADVC Series
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
ADVC-6-5-A-P
- Product data
- CAD data not available
Basic information
| Cylinder Operation Method | Double Acting | Stroke: L(mm) | 5 | Operating Temperature(℃) | -20::80 |
|---|---|---|---|---|---|
| Operating Pressure(MPa) | 0.15::0.8 | Housing material | Wrought aluminum alloy, Anodized | Seals material | NBR, TPE-U(PU) |
| Cover material | Wrought aluminum alloy, Anodized | Piston rod material | High-alloy steel | Piston diameter(mm) | 6 |
| Theoretical force at 6 bar, retracting(N) | 13 | Theoretical force at 6 bar, advancing(N) | 17 | Pneumatic connection | M3 |
| Moving mass(g) | 1.2 | Operating medium | Compressed air as per ISO 8573-1:2010 [7:4:4] | Corrosion resistance class (CRC) | 1 - Low corrosion stress |
| Manufacturer part # | 188066 | Weight | 12.5 |
This page is Short-stroke cylinder, ADVC Series, part number ADVC-6-5-A-P.
You can find the detail information about specifications and dimensions on part number ADVC-6-5-A-P.
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
