Basic switch for position switch Enclosure plastic
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
3SE51320PA00
- Product data
- CAD data not available
Basic information
| Operating Temperature Range(°C) | -25::85 | Contact material | Silver alloy | Product size (width)(mm) | 40 |
|---|---|---|---|---|---|
| Product size (depth)(mm) | 37.3 | Product size (length)(mm) | 85.7 | Actuating force(N) | 20 |
| Switching current (max.)(A) | 6 | Electrical lifespan | 100000 | Thread size | M20 x 1.5 |
| Durability | 15000000 | IP rating | IP66, IP67 | Connection (components) | Screws |
| Compatible with (details) | For Position Switch | Contact type | 1 breaker, 2 makers, 1 change-over | Material | Plastic |
This page is Basic switch for position switch Enclosure plastic, part number 3SE51320PA00.
You can find the detail information about specifications and dimensions on part number 3SE51320PA00.
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
