Polling Units, with sensor
The polling unit is always built into a seating element as a single system. By means of a simple plug-in connection, it transmits whether a part is located at a specific position, as an electrical signal.
The polling unit can be used in combination with various seating elements. For example, the EH 22690 pins from the Halder standard parts are suitable.
Data is transferred via a cable connection. Optionally, the polling signal can be transferred by radio.
The interrogation unit meets the requirements of protection class IP6K7 (highly temperature-resistant and robust).
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Product data
- CAD data not available
Part Number
|
|---|
| 22810.0008 |
| 22810.0012 |
| 22810.1008 |
| 22810.1012 |
| Part Number | Related to |
Standard Unit Price
| Minimum order quantity | Volume Discount | Type | for taper clamping units | d1 | d2 (mm) | d3 (mm) | h1 min. (mm) | h1 max. (mm) | h2 (mm) | h3 (mm) | h4 max. (mm) | l1 (mm) | l2 (mm) | l3 (mm) | WS1 (mm) | WS2 (mm) | WS3 (mm) | Weight (g) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
289.85 € | 1 | 2 Days | With bushing | 22810.9010 | M8 | M8 | 20.3 | 30.5 | 40.5 | 5 | 12 | 20 | 12 | 15.8 | 21.4 | 30 | 1.5 | 1.5 | 180 | |||
296.58 € | 1 | 2 Days | With bushing | 22810.9010 | M12 | M12 | 25.5 | 41.5 | 59 | 8 | 15 | 27.5 | 15 | 18.7 | 24.3 | 36 | 2 | 2 | 300 | |||
289.85 € | 1 | 2 Days | With plug | - | M8 | M8 | 20.3 | 30.5 | 40.5 | 5 | 12 | 20 | 12 | 15.8 | 21.4 | 30 | 1.5 | 1.5 | 180 | |||
296.58 € | 1 | 2 Days | With plug | - | M12 | M12 | 25.5 | 41.5 | 59 | 8 | 15 | 27.5 | 15 | 18.7 | 24.3 | 36 | 2 | 2 | 300 |
Loading...
Basic information
| Body | Aluminium, blue anodised | Body 2 | Heat-treated steel, tempered, blackened | Cable | Silicone |
|---|---|---|---|---|---|
| Sensor | Plastic, black | Plug | Metal | h4 min.(mm) | 10 |
| Temperature min.(°C) | -25 | Temperature max.(°C) | 85 | Conflict Minerals free | yes |
Configure
Basic Attributes
-
Type
- With bushing
- With plug
-
for taper clamping units
- 22810.9010
-
d1
- M8
- M12
-
d2(mm)
- M8
- M12
-
d3(mm)
- 20.3
- 25.5
-
h1 min.(mm)
- 30.5
- 41.5
-
h1 max.(mm)
- 40.5
- 59
-
h2(mm)
- 5
- 8
-
h3(mm)
- 12
- 15
-
h4 max.(mm)
- 20
- 27.5
-
l1(mm)
- 12
- 15
-
l2(mm)
- 15.8
- 18.7
-
l3(mm)
- 21.4
- 24.3
-
WS1(mm)
- 30
- 36
-
WS2(mm)
- 1.5
- 2
-
WS3(mm)
- 1.5
- 2
Filter by standard shipping days
-
- All
- 2 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
