Radio Transmitters, for polling unit
For cable-free transfer of the polled signal.
The radio transmitter is installed close to the polling unit, and is connected to the plug of the polling unit. The transmitter makes the polled signal available by radio, and does not require additional cable connection. Power is supplied by a battery.
The radio transmitter meets the requirements of protection class IP 67 (robust material) and is therefore suitable for use with cooling lubricants.
Frequency: 868.3 MHz (EU, Switzerland)
Other frequencies available on request.
The radio transmitter is installed close to the polling unit, and is connected to the plug of the polling unit. The transmitter makes the polled signal available by radio, and does not require additional cable connection. Power is supplied by a battery.
The radio transmitter meets the requirements of protection class IP 67 (robust material) and is therefore suitable for use with cooling lubricants.
Frequency: 868.3 MHz (EU, Switzerland)
Other frequencies available on request.
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
22810.9010
- Product data
- CAD data not available
Basic information
| Acquired Standards | CE | for taper clamping units | 22810.0008 / .0012 | d1 | M12 x 1 |
|---|---|---|---|---|---|
| d2(mm) | 4.5 | b1(mm) | 36 | b2(mm) | 64 |
| h1(mm) | 37 | h2(mm) | 52 | l1(mm) | 86 |
| l2(mm) | 99 | Conflict Minerals free | yes | Weight(g) | 191 |
This page is Radio Transmitters, for polling unit, part number 22810.9010.
You can find the detail information about specifications and dimensions on part number 22810.9010.
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
