Deep groove ball bearings / single row / 2Z / 2ZC3AS22 / ZEN
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
S6000 -2ZC3AS22
- Product data
- CAD data not available
Basic information
| Materials of Inner and Outer Ring | Stainless Steel | Accuracy (JIS) | Grade 0 | I.D. D(φ) | 10 |
|---|---|---|---|---|---|
| Outer Diameter D(φ) | 26 | Width B(mm) | 8 | Number of Bearing Ring Rows | Single Row |
| Rolling Element Material | Stainless Steel | Bore | Cylindrical bore | Cage | Sheet steel cage |
| Clearance | Slightly increased radial clearance | Current insulation | No current insulation | Outer ring | Without flange/groove |
| Seal | Cover on both sides | Temperature range | Special greasing (-65 to +204 °C) | Weight(g) | 19.0 |
This page is Deep groove ball bearings / single row / 2Z / 2ZC3AS22 / ZEN, part number S6000 -2ZC3AS22.
You can find the detail information about specifications and dimensions on part number S6000 -2ZC3AS22.
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
