Deep groove ball bearings / single row / 689 / J / ZEN

Deep groove ball bearings / single row / 689 / J / ZEN

ZEN

ZEN

Part Number

Once your search is narrowed to one product,
the corresponding part number is displayed here.

Data to be displayed
30
45
60
  1. 1
Part Number
686 J
S689 J
Part Number
Standard Unit Price
Minimum order quantityVolume Discount
Standard
Shipping Days
?
Materials of Inner and Outer Ring I.D. D
(φ) 		Outer Diameter D
(φ) 		Width B
(mm) 		Rolling Element Material Weight
(g)

0.93 €

1 4 Days Steel6133.5Steel3.0

2.10 €

1 4 Days Stainless Steel9174Stainless Steel5.0

Loading...

  1. 1

Basic information

Accuracy  (JIS) Grade 0 Number of Bearing Ring Rows Single Row Bore Cylindrical bore
Cage Sheet steel cage Clearance Normal radial clearance Current insulation No current insulation
Outer ring Without flange/groove Seal None. open bearing Temperature range -20 to +120 °C

Configure

Clear all

2Suggestion of an applicable part number.

View Part Numbers

Some specification is not specified yet.
The part number is completed.

Basic Attributes

  • Materials of Inner and Outer Ring

  • I.D. D(φ)

  • Outer Diameter D(φ)

  • Width B(mm)

  • Rolling Element Material

  • Weight(g)
