PARKER Parkrimp No-Skive Fitting 16A70
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Product data
- CAD data not available
Part Number
|
|---|
| 16A70-12-12-1P |
| 16A70-16-12-1P |
| 16A70-16-16-1P |
| 16A70-20-16-1P |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Nominal Dia. (mm) | A (mm) | Customs tariff weight (kg) | Thread or tube size | B (mm) | Hose fitting size | F (mm) | Imperial flange size | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
98.98 € | 1 | 5 Days | 19 | 105 | 0.343 | -12 | 66 | -12 | 41 | 3/4 | ||
126.91 € | 1 | 5 Days | 19 | 110 | 0.345 | -16 | 70 | -12 | 48 | 1 | ||
124.69 € | 1 | 5 Days | 25 | 127 | 0.603 | -16 | 82 | -16 | 48 | 1 | ||
138.78 € | 1 | 5 Days | 25 | 127 | 0.544 | -20 | 82 | -16 | 54 | 1-1/4 |
Loading...
Basic information
| Customs tariff weight unit | kg | Steel | Galvanized steel, Cr(VI)-free | Connection group | Flange |
|---|---|---|---|---|---|
| Norm | ISO 12151-3-S-S | Common name | SFS / 6,000 psi | Description of connection type | ISO 6162-2 - flange - heavy design - 6,000 psi |
| Connection type | 6A | Fitting series | 70 | Customs tariff item number | 73269098 |
| Operating pressure Mpa | 42 | Customs tariff weight per | 1 | Fitting | Parkrimp fitting |
| Customs tariff country of origin | DE |
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
