Grooved Nut, Imperial
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Product data
- CAD data not available
Part Number
|
|---|
| AN 16 |
| AN 24 |
| N 09 |
| N 11 |
| N 12 |
| N 13 |
| N 14 |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Weight (g) | width in mm | internal diameter in mm | external diameter in mm | GTIN/EAN | series | Customs tariff number | |
|---|---|---|---|---|---|---|---|---|---|---|---|
44.56 € | 1 | 17 Days | 417.0 | 15.342 | 79.68 | 105.689 | 7316571353487 | AN | 73181660 | ||
86.95 € | 1 | 17 Days | 1057.0 | 20.904 | 119.786 | 155.702 | 7316576660474 | AN | 84829900 | ||
10.30 € | 1 | 17 Days | 140.0 | 11.379 | 44.882 | 64.414 | - | N | 73181660 | ||
11.68 € | 1 | 17 Days | 188.0 | 12.7 | 54.788 | 75.406 | 7316571385686 | N | 73181660 | ||
15.23 € | 1 | 17 Days | 210.0 | 13.741 | 59.944 | 80.289 | 7316571280721 | N | 73181660 | ||
16.75 € | 1 | 12 Days | 250.0 | 14.288 | 64.719 | 85.725 | 7316571385488 | N | 73181660 | ||
26.58 € | 1 | 17 Days | 291.0 | 14.554 | 69.875 | 92.202 | 7316571385471 | N | 84829900 |
Loading...
Basic information
| Material | Steel | number of grooves | 4 ST | backup type | locking plate |
|---|
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
