Double Cup Seal, 90NBR
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Product data
- CAD data not available
Part Number
|
|---|
| 11606 |
| 11618 |
| 63684 |
| 9634 |
| 9640 |
| 9651 |
| 9654 |
| 9733 |
| 9746 |
| 9755 |
| 9777 |
| 9791 |
| 9795 |
| 9811 |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Outer Diameter (mm) | Internal Diameter (φ) | Width (mm) | Weight (g) | |
|---|---|---|---|---|---|---|---|---|
396.13 € | 1 | Available | 17 Days | 200 | 20 | 40 | 2560 | |
115.06 € | 1 | Available | 17 Days | 75 | 12 | 30 | 204.43 | |
103.38 € | 1 | Available | 17 Days | 63 | 12 | 25 | 114.3 | |
85.97 € | 1 | Available | 17 Days | 35 | 8 | 26 | 30 | |
89.54 € | 1 | Available | 17 Days | 40 | 10 | 25 | 46.07 | |
92.47 € | 1 | Available | 17 Days | 45 | 10 | 25 | 61.53 | |
95.38 € | 1 | Available | 12 Days | 50 | 10 | 25 | 79.9 | |
112.01 € | 1 | Available | 17 Days | 80 | 12 | 30 | 225.37 | |
150.76 € | 1 | Available | 12 Days | 90 | 12 | 30 | 348.92 | |
170.40 € | 1 | Available | 17 Days | 100 | 12 | 35 | 404.001 | |
218.88 € | 1 | Available | 17 Days | 125 | 20 | 40 | 821.301 | |
283.11 € | 1 | Available | 12 Days | 150 | 20 | 40 | 1441.201 | |
277.27 € | 1 | Available | 17 Days | 160 | 20 | 40 | 1661.2 | |
827.12 € | 1 | Available | 17 Days | 300 | 60 | 40 | 6771 |
Loading...
Basic information
| Hardness in Shore | 90 | Series | T-DUO-H | Material | NBR |
|---|---|---|---|---|---|
| Customs tariff number | 40169300 |
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
