Jaw Coupling / KKYS / ABP Antriebstechnik
- Volume Discount
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Product data
- CAD data not available
Part Number
|
|---|
| KKYS 1500 06/06 80 |
| KKYS 1500 06/06 92 |
| KKYS 1500 06/06 98 |
| KKYS 1500 06/10 80 |
| KKYS 1500 06/10 92 |
| KKYS 1500 06/10 98 |
| KKYS 1500 10/10 80 |
| KKYS 1500 10/10 92 |
| KKYS 1500 10/10 98 |
| Part Number | Related to |
Standard Unit Price
| Minimum order quantity | Volume Discount | Shaft Bore Dia. (machined) D1 (mm) | Shaft Bore Dia. (machined) D2 (mm) | Moment of Inertia (g･cm2) | |
|---|---|---|---|---|---|---|---|---|
76.62 € | 1 | Available | 5 Days | 6 | 6 | 8 | ||
76.62 € | 1 | Available | 5 Days | 6 | 6 | 15 | ||
76.62 € | 1 | Available | 5 Days | 6 | 6 | 25 | ||
76.62 € | 1 | Available | 5 Days | 6 | 10 | 8 | ||
76.62 € | 1 | Available | 5 Days | 6 | 10 | 15 | ||
76.62 € | 1 | Available | 5 Days | 6 | 10 | 25 | ||
76.62 € | 1 | Available | 5 Days | 10 | 10 | 8 | ||
76.62 € | 1 | Available | 5 Days | 10 | 10 | 15 | ||
76.62 € | 1 | Available | 5 Days | 10 | 10 | 25 |
Loading...
Basic information
| Type | Jaw Type | Body Material | Steel | Max. Rotational Speed(r/min) | 19.000 |
|---|---|---|---|---|---|
| Allowable Lateral Misalignment(mm) | ±0.22 | Allowable Angular Misalignment(deg) | ±1.3 | Buffer Part Material | Polyurethane |
| Operating Temperature Range(°C) | -30::+80 | Allowable Axial Clearance (±)(mm) | ±1 | Hardness damping element(shore hardness) | 30 |
| Torsion Spring Stiffness(Nm/rad) | 89 |
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
