Super-Elastic Solid Rubber Tyres, BSEV Series
Tyre:
- super-elastic solid rubber, steel-wire reinforced, hardness 70 Shore A
- very good operational comfort
- very good floor preservation, low-noise operation
- colour black
- wheel Ø 250–306 mm: 2-component tyre, highly-elastic, abrasion-resistant tread
- wheel Ø 405 mm: 3-component tyre, highly-elastic cushion layer, abrasion-resistant tread
- chemical resistance to many aggressive substances, except oils
- operating temperature: -30 °C to +80 °C, temporarily up to +100 °C, reduced load capacity over +60 °C
- tyre for installation on the standard rims specified in the table
- The tyre dimensions provided here apply to new tyres that are not bearing a load. The dimensions may change when they are in use.
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Product data
- CAD data not available
Part Number
|
|---|
| BSEV 3.00-4 |
| BSEV 3.00-4/2.50-4 |
| BSEV 3.00-4/2.50-4-RP |
| BSEV 3.00-4-RP |
| BSEV 4.00-4 |
| BSEV 4.00-4-RP |
| BSEV 4.00-8 |
| BSEV 4.00-8-RP |
| BSEV 5.00-8 |
| BSEV 6.00-9 |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | O.D. D (Ø) | Width W (mm) | Load (Reference) (N) | Weight (kg) | Load capacity at 4km/h (kg) | |
|---|---|---|---|---|---|---|---|---|---|
115.09 € | 1 | 5 Days | 250 | 85 | 4708.8 | 3.698 | 480 | ||
115.09 € | 1 | 5 Days | 250 | 85 | 7063.2 | 3.757 | 720 | ||
115.09 € | 1 | 5 Days | 250 | 85 | 7063.2 | 3.831 | 720 | ||
115.09 € | 1 | 5 Days | 250 | 85 | 4708.8 | 3.915 | 480 | ||
197.23 € | 1 | 5 Days | 306 | 105 | 8240.4 | 6.83 | 840 | ||
197.23 € | 1 | 5 Days | 306 | 105 | 8240.4 | 7.176 | 840 | ||
325.95 € | 1 | 5 Days | 405 | 105 | 11.18 | 10.45 | 1140 | ||
325.95 € | 1 | 5 Days | 405 | 105 | 11.18 | 10.78 | 1140 | ||
465.52 € | 1 | 5 Days | 455 | 120 | 16.68 | 16.125 | 1700 | ||
756.38 € | 1 | 5 Days | 525 | 140 | 22.17 | 25.5 | 2260 |
Loading...
Basic information
| Lining Hardness(Shore A) | 70 Shore A | Antistatic | no | Suitable for autoclaves | no |
|---|---|---|---|---|---|
| Tread and tyre hardness | 70 Shore A | Electrically conductive | no | Tread color | black |
| Heat-resistant | no | Tread hydrolysis-resistant | yes | Non-staining | no |
| Tread material | Rubber | Product type | tyre | Rustproof | no |
| Non-marking | no | Max. temperature resistance(° C) | 80 | Min. temperature resistance(° C) | -30 |
Configure
Basic Attributes
-
O.D. D(Ø)
-
Width W(mm)
-
Load (Reference)(N)
-
Weight(kg)
-
Load capacity at 4km/h(kg)
-
Type
- BSEV
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
