Heavy Duty Welded Steel Fixed Castor, BS-P Series
Bracket: BS series
- particularly robust welded steel construction
- zinc-plated, yellow-passivated, Cr6-free
Wheel: P series
- tyre: pneumatic tyre with ribbed profile, hardness 60 Shore A, colour black, 4-ply rating
- rim: pressed steel, with welded tubular steel hub
- lacquered, colour silver
- swivel castors with brakes lose brake force if the tyre pressure is too low
- chemical resistance to many aggressive substances, except oils
- operating temperature: -20 °C to +50 °C
- the wheel and tyre dimensions provided here apply to new tyres that are not bearing a load. Their width and diameter may change when they are in use.
- speeds up to 16 km/h possible for wheels with ball bearing and reduced load capacity
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Product data
- CAD data not available
Part Number
|
|---|
| BS-P 410K |
| BS-P 420K |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Caster Type | Mounting Height H (mm) | Load Range (daN) | Wheel Dia. D (mm) | Wheel Width B (mm) | Total height (mm) | Weight (g) | Wheel diameter (mm) | Wheel width (mm) | Load capacity at 4 km/h (kg) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
435.23 € | 1 | 7 Days | Plate Type Swivel / Screw-In Type / Through Hole Type / Rotation Type | 623 | 320.01 to 485.00 | 536 | 165 | 470 | 9948 | 400 | 100 | 350 | ||
460.67 € | 1 | 7 Days | Plate Type Swivel / Screw-In Type / Resin / Through Hole Type / Rotation Type | 675 | 485.01 to 750.00 | 500 | 130 | 478 | 10520 | 415 | 115 | 525 |
Loading...
Basic information
| Wheel Material | Steel | Plate Length L(mm) | 200 | Plate Width W(mm) | 160 |
|---|---|---|---|---|---|
| Bearing type | Ball bearing | Material (details) | Tread material: Rubber, Wheel body material: pressed steel | Material | Rubber |
| Product type | fixed castor | Suitable for autoclaves | no | Mounting type | top plate |
| Tread and tyre hardness | 60 Shore A | Tread color | black | Wheel body color | silver |
| Tread hydrolysis-resistant | no | Non-staining | no | Rustproof | no |
| Non-marking | no | Maximum temperature resistance(°C) | 50 | Minimum temperature resistance(°C) | -20 |
Configure
Basic Attributes
-
Caster Type
- Plate Type Swivel
- Screw-In Type
- Resin
- Through Hole Type
- Rotation Type
-
Mounting Height H(mm)
-
Load Range(daN)
- 320.01 to 485.00
- 485.01 to 750.00
-
Wheel Dia. D(mm)
-
Wheel Width B(mm)
-
Total height(mm)
-
Weight(g)
-
Wheel diameter(mm)
-
Wheel width(mm)
-
Load capacity at 4 km/h(kg)
-
Type
- BS-P
Filter by standard shipping days
-
- All
- 7 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
