Nylon Wheel, POA Series
Wheel:
- high-quality nylon 6, impact resistant, hardness 70 Shore D
- excellent rolling and swivel resistance
- easy operation on smooth surfaces
- high abrasion resistance
- colour black
- high chemical resistance to many aggressive substances
- operating temperature: -25 °C to +80 °C, reduced load capacity over +35 °C
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Product data
- CAD data not available
Part Number
|
|---|
| POA 35/8G |
| POA 50/8G |
| POA 52/12G |
| POA 58/10G |
| POA 65/10G |
| POA 65/12G |
| POA 75/8G |
| POA 80/12G |
| POA 100/8K |
| POA 100/12G |
| POA 102/8G |
| POA 125/8K |
| POA 125/12G |
| POA 150/12G |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Wheel O.D. (mm) | Wheel Width (mm) | Hole Diameter (mm) | Hub Width (mm) | Max. Load / Allowable Load (daN) | Max. Load / Allowable Load (kg) | Bearing type | Weight (g) | Rustproof | Min. temperature resistance (° C) | Load capacity at 3km/h (kg) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
0.86 € | 1 | 5 Days | 35 | 25 | 8 | 29,5 | 75 | 75 | plain bore | 18 | yes | -25 | 75 | ||
1.05 € | 1 | 5 Days | 50 | 18 | 8 | 22 | 75 | 75 | plain bore | 19 | yes | -25 | 75 | ||
2.53 € | 1 | 5 Days | 50 | 29 | 12 | 31 | 120 | 120 | plain bore | 41 | yes | -25 | 120 | ||
2.61 € | 1 | 5 Days | 58 | 29 | 10 | 31 | 100 | 100 | plain bore | 42 | yes | -25 | 100 | ||
2.79 € | 1 | 5 Days | 65 | 30 | 10 | 33 | 100 | 100 | plain bore | 53 | yes | -25 | 100 | ||
3.48 € | 1 | 5 Days | 65 | 30 | 12 | 33 | 100 | 100 | plain bore | 52 | yes | -25 | 100 | ||
2.70 € | 1 | 5 Days | 75 | 23 | 8 | 29,5 | 100 | 100 | plain bore | 46 | yes | -25 | 100 | ||
4.26 € | 1 | 5 Days | 80 | 32 | 12 | 35 | 220 | 220 | plain bore | 86 | yes | -25 | 220 | ||
16.47 € | 1 | 5 Days | 100 | 30 | 8 | 36 | 240 | 240 | ball bearing (C) | 184 | no | -20 | 240 | ||
5.24 € | 1 | 5 Days | 100 | 32 | 12 | 35 | 240 | 240 | plain bore | 113 | yes | -25 | 240 | ||
6.00 € | 1 | 5 Days | 100 | 22 | 8 | 29,5 | 100 | 100 | plain bore | 90 | yes | -25 | 100 | ||
19.95 € | 1 | 5 Days | 125 | 30 | 8 | 36 | 260 | 260 | ball bearing (C) | 230 | no | -20 | 260 | ||
10.28 € | 1 | 5 Days | 125 | 32 | 12 | 35 | 260 | 260 | plain bore | 159 | yes | -25 | 260 | ||
15.07 € | 1 | 5 Days | 150 | 32 | 12 | 35 | 280 | 280 | plain bore | 248 | yes | -25 | 280 |
Loading...
Basic information
| Wheel Material | Resin | Bearing | Provided | Wheel Material | Resin |
|---|---|---|---|---|---|
| Material (details) | high-quality nylon 6 | Product type | wheel | Antistatic | no |
| Suitable for autoclaves | no | Tread and tyre hardness | 70 Shore D | Electrically conductive | no |
| Tread color | black | Wheel body colour | black | Heat-resistant | no |
| Tread hydrolysis-resistant | no | Non-staining | yes | Tread material | Synthetic |
| Non-marking | yes | Max. temperature resistance(° C) | 80 |
Configure
Basic Attributes
-
Wheel O.D.(mm)
-
Wheel Width(mm)
-
Hole Diameter(mm)
-
Hub Width(mm)
-
Max. Load / Allowable Load(daN)
-
Max. Load / Allowable Load(kg)
-
Bearing type
- ball bearing (C)
- plain bore
-
Weight(g)
-
Rustproof
- no
- yes
-
Min. temperature resistance(° C)
- -25
- -20
-
Load capacity at 3km/h(kg)
-
Type
- POA
Filter by standard shipping days
-
- All
- 5 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
