Tension lever flat, form 15°, steel, inch (06400)
· Makes it easier to clamp individual components and complete machine parts
· Application fields: machine construction, plant construction, rehabilitation and medical technology, furniture industry
· Ideal where space is restricted
· Flat design offers additional safety advantages
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Product data
- CAD data not available
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Handle length (mm) | H | D | Size | X=thread | D1 (mm) | No. of teeth | D2 | D3 | H2 | H3 | H4 | L=thread length | Weight in kg (ERP) (kg) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
28.91 € | 1 | 4 Days | 100 | 19 | 13.5 | 1 | 5/16-18 | 33 | 20 | 25 | 10 | 12 | 23 | 29 | 20 | 0.1770 | ||
28.91 € | 1 | 4 Days | 100 | 19 | 13.5 | 1 | 5/16-18 | 33 | 20 | 25 | 10 | 12 | 23 | 29 | 25 | 0.1800 | ||
28.91 € | 1 | 4 Days | 100 | 19 | 13.5 | 1 | 5/16-18 | 33 | 20 | 25 | 10 | 12 | 23 | 29 | 30 | 0.1799 | ||
30.35 € | 1 | 4 Days | 100 | 19 | 13.5 | 1 | 5/16-18 | 33 | 20 | 25 | 10 | 12 | 23 | 29 | 40 | 0.1815 | ||
30.35 € | 1 | 4 Days | 100 | 19 | 13.5 | 1 | 5/16-18 | 33 | 20 | 25 | 10 | 12 | 23 | 29 | 50 | 0.1860 | ||
30.35 € | 1 | 4 Days | 100 | 19 | 13.5 | 1 | 5/16-18 | 33 | 20 | 25 | 10 | 12 | 23 | 29 | 60 | 0.1891 | ||
28.91 € | 1 | 4 Days | 100 | 19 | 13.5 | 1 | 3/8-16 | 33 | 20 | 25 | 10 | 12 | 23 | 29 | 20 | 0.1802 | ||
28.91 € | 1 | 4 Days | 100 | 19 | 13.5 | 1 | 3/8-16 | 33 | 20 | 25 | 10 | 12 | 23 | 29 | 25 | 0.1800 | ||
28.91 € | 1 | 4 Days | 100 | 19 | 13.5 | 1 | 3/8-16 | 33 | 20 | 25 | 10 | 12 | 23 | 29 | 30 | 0.1820 | ||
30.35 € | 1 | 4 Days | 100 | 19 | 13.5 | 1 | 3/8-16 | 33 | 20 | 25 | 10 | 12 | 23 | 29 | 40 | 0.1871 | ||
30.35 € | 1 | 4 Days | 100 | 19 | 13.5 | 1 | 3/8-16 | 33 | 20 | 25 | 10 | 12 | 23 | 29 | 50 | 0.1918 | ||
30.35 € | 1 | 4 Days | 100 | 19 | 13.5 | 1 | 3/8-16 | 33 | 20 | 25 | 10 | 12 | 23 | 29 | 60 | 0.1968 | ||
35.34 € | 1 | 4 Days | 127 | 22 | 19 | 2 | 3/8-16 | 41 | 24 | 30 | 12 | 13.5 | 26 | 38 | 20 | 0.3170 | ||
35.34 € | 1 | 4 Days | 127 | 22 | 19 | 2 | 3/8-16 | 41 | 24 | 30 | 12 | 13.5 | 26 | 38 | 25 | 0.3130 | ||
35.34 € | 1 | 4 Days | 127 | 22 | 19 | 2 | 3/8-16 | 41 | 24 | 30 | 12 | 13.5 | 26 | 38 | 30 | 0.3188 | ||
36.96 € | 1 | 4 Days | 127 | 22 | 19 | 2 | 3/8-16 | 41 | 24 | 30 | 12 | 13.5 | 26 | 38 | 40 | 0.3190 | ||
36.96 € | 1 | 4 Days | 127 | 22 | 19 | 2 | 3/8-16 | 41 | 24 | 30 | 12 | 13.5 | 26 | 38 | 50 | 0.3310 | ||
36.96 € | 1 | 4 Days | 127 | 22 | 19 | 2 | 3/8-16 | 41 | 24 | 30 | 12 | 13.5 | 26 | 38 | 60 | 0.3270 | ||
35.34 € | 1 | 4 Days | 127 | 22 | 19 | 2 | 1/2-13 | 41 | 24 | 30 | 12 | 13.5 | 26 | 38 | 20 | 0.3274 | ||
35.34 € | 1 | 4 Days | 127 | 22 | 19 | 2 | 1/2-13 | 41 | 24 | 30 | 12 | 13.5 | 26 | 38 | 25 | 0.3280 | ||
35.34 € | 1 | 4 Days | 127 | 22 | 19 | 2 | 1/2-13 | 41 | 24 | 30 | 12 | 13.5 | 26 | 38 | 30 | 0.3310 | ||
36.96 € | 1 | 4 Days | 127 | 22 | 19 | 2 | 1/2-13 | 41 | 24 | 30 | 12 | 13.5 | 26 | 38 | 40 | 0.3386 | ||
36.96 € | 1 | 4 Days | 127 | 22 | 19 | 2 | 1/2-13 | 41 | 24 | 30 | 12 | 13.5 | 26 | 38 | 50 | 0.3526 | ||
36.96 € | 1 | 4 Days | 127 | 22 | 19 | 2 | 1/2-13 | 41 | 24 | 30 | 12 | 13.5 | 26 | 38 | 60 | 0.3546 | ||
42.03 € | 1 | 4 Days | 145 | 28 | 23 | 3 | 1/2-13 | 45 | 26 | 37 | 14 | 17 | 33 | 48 | 20 | 0.5033 | ||
42.03 € | 1 | 4 Days | 145 | 28 | 23 | 3 | 1/2-13 | 45 | 26 | 37 | 14 | 17 | 33 | 48 | 25 | 0.5709 | ||
42.03 € | 1 | 4 Days | 145 | 28 | 23 | 3 | 1/2-13 | 45 | 26 | 37 | 14 | 17 | 33 | 48 | 30 | 0.5113 | ||
43.73 € | 1 | 4 Days | 145 | 28 | 23 | 3 | 1/2-13 | 45 | 26 | 37 | 14 | 17 | 33 | 48 | 40 | 0.5200 | ||
43.73 € | 1 | 4 Days | 145 | 28 | 23 | 3 | 1/2-13 | 45 | 26 | 37 | 14 | 17 | 33 | 48 | 50 | 0.5260 | ||
43.73 € | 1 | 4 Days | 145 | 28 | 23 | 3 | 1/2-13 | 45 | 26 | 37 | 14 | 17 | 33 | 48 | 60 | 0.5354 | ||
42.03 € | 1 | 4 Days | 145 | 28 | 23 | 3 | 5/8-11 | 45 | 26 | 37 | 14 | 17 | 33 | 48 | 20 | 0.5109 | ||
42.03 € | 1 | 4 Days | 145 | 28 | 23 | 3 | 5/8-11 | 45 | 26 | 37 | 14 | 17 | 33 | 48 | 25 | 0.5154 | ||
42.03 € | 1 | 4 Days | 145 | 28 | 23 | 3 | 5/8-11 | 45 | 26 | 37 | 14 | 17 | 33 | 48 | 30 | 0.5241 | ||
43.73 € | 1 | 4 Days | 145 | 28 | 23 | 3 | 5/8-11 | 45 | 26 | 37 | 14 | 17 | 33 | 48 | 40 | 0.5386 | ||
43.73 € | 1 | 4 Days | 145 | 28 | 23 | 3 | 5/8-11 | 45 | 26 | 37 | 14 | 17 | 33 | 48 | 50 | 0.5504 | ||
43.73 € | 1 | 4 Days | 145 | 28 | 23 | 3 | 5/8-11 | 45 | 26 | 37 | 14 | 17 | 33 | 48 | 60 | 0.5138 |
Loading...
Basic information
| Main material | Steel | Grade | 5.8 | Surface finish body | black oxidised |
|---|---|---|---|---|---|
| Component material | Plastic | Form | 15° | A2 | 15 |
| H1 | 2 | Item | Tension Lever | Kind of fastening | internal thread |
| Version 1 | flat | RoHS | yes | PL Edelstahl | no |
