Clamping lever flat, internal thread, zinc, plastic-coated, inch (06448)
· Makes it easier to clamp individual components and complete machine parts
· Application fields: machine construction, plant construction, rehabilitation and medical technology, furniture industry
· Flat grip for tight spaces
· Flat design offers additional safety advantages
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Product data
- CAD data not available
Part Number
|
|---|
| 06448-2A22 |
| 06448-2A32 |
| 06448-3A32 |
| 06448-3A42 |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Handle length (mm) | H | B | D | Size | X=thread | D1 (mm) | No. of teeth | A1=Handle length | D2 | H1 | H2 | H3=handle height | H4 | T=thread depth | Weight in kg (ERP) (kg) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
10.71 € | 1 | 4 Days | 65 | 28.5 | 10.1 | 13.5 | 2 | 1/4-20 | 18.5 | 20 | 74.5 | 19.1 | 6.5 | 17.8 | 29.2 | 32.2 | 12 | 0.0782 | ||
10.71 € | 1 | 4 Days | 65 | 28.5 | 10.1 | 13.5 | 2 | 5/16-18 | 18.5 | 20 | 74.5 | 19.1 | 6.5 | 17.8 | 29.2 | 32.2 | 12 | 0.0764 | ||
11.70 € | 1 | 4 Days | 80 | 37 | 11.7 | 16 | 3 | 5/16-18 | 21.2 | 22 | 91 | 22 | 10 | 23.8 | 38 | 42 | 14 | 0.1272 | ||
11.70 € | 1 | 4 Days | 80 | 37 | 11.7 | 16 | 3 | 3/8-16 | 21.2 | 22 | 91 | 22 | 10 | 23.8 | 38 | 42 | 14 | 0.1252 |
Loading...
Basic information
| Main material | Zinc | Surface finish body | plastic-coated | Main colour | orange RAL 2004 |
|---|---|---|---|---|---|
| Component material | Steel | Surface finish component | black oxidised | Item | Clamping Lever |
| Thread type | internal thread | Version 1 | flat | RoHS | yes |
Configure
Basic Attributes
-
Handle length(mm)
-
H
-
B
-
D
-
Size
-
X=thread
-
D1(mm)
-
No. of teeth
-
A1=Handle length
-
D2
-
H1
-
H2
-
H3=handle height
-
H4
-
T=thread depth
