Wire to Wire Connector Terminal with 2.00 mm Pitch (50012)
- Volume Discount
[Features]
• Single-row Molex connector with few terminals (compatible housing 51006).
· Core wire sizes: AWG #24 through #28.
· Coating outer diameter: ∅ 0.9 to 1.15 mm.
· Strip length: 1.7 to 2.3 mm
• Single-row Molex connector with few terminals (compatible housing 51006).
· Core wire sizes: AWG #24 through #28.
· Coating outer diameter: ∅ 0.9 to 1.15 mm.
· Strip length: 1.7 to 2.3 mm
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
50012-8100
Basic information
| Applicable pin/contact | Male (plug) | Application | Cable Connection | Allowable Current(A) | 2 |
|---|---|---|---|---|---|
| Allowable Voltage(V) | 125 | Wire connection method | Crimp | Conforming housing | 51006 |
| Applicable size AWG | 24–28 | Terminal shape | Individual | Mating Partner | 50013 |
| Applicable wire coating outer diameter(mm) | 1.15 |
This page is Wire to Wire Connector Terminal with 2.00 mm Pitch (50012), part number 50012-8100.
You can find the detail information about specifications and dimensions on part number 50012-8100.
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
