2-conductor Ex e II through terminal block 280【100 Pieces Per Package】
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Part Number
|
|---|
| 280-691 |
| 280-992 |
| Part Number | Related to |
Standard Unit Price
| Number of pc(s). included in pkg. | Minimum order quantity | Volume Discount | Number of pins (Pole) | Min. cross section (flexible) (mm²) | Min. cross section (inflexible) (mm²) | AWG (min.) | |
|---|---|---|---|---|---|---|---|---|---|---|
147.05 € | 100 Pieces Per Package | 1 pack | Available | 7 Days | 2 | 0.2 | 0.2 | 24 | ||
158.49 € | 100 Pieces Per Package | 1 pack | Available | 25 Days | 1 | 0.08 | 0.08 | 28 |
Loading...
Basic information
| Product size (height)(mm) | 28 | Product size (width)(mm) | 5 | Clamp width(mm) | 5 |
|---|---|---|---|---|---|
| Stripping length (max.)(mm) | 9 | Min. stripping length(mm) | 8 | Nominal current(A) | 23 |
| Nominal voltage(V) | 550 | Max. cross section (flexible)(mm²) | 2.50 | Max. cross section (inflexible)(mm²) | 2.5 |
| AWG max. | 14 | No. of rows | 1 | Pins per row | 2 |
| Colour | Grey | Connector type (category) | Continuity | Configuration | L |
| Connection (components) | Pull spring | Connector features | Complies with ATEX Ex-e II standards | Industrial goods | Yes |
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
