Spring-loaded terminal, 235【600 Pieces Per Package】
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
235-551/331-000
Basic information
| Number of pins(Pole) | 1 | Color | Grey | AWG max. | 18 |
|---|---|---|---|---|---|
| AWG (min.) | 24 | Contact spacing(mm) | 7.62 | Max. cross section (inflexible)(mm²) | 0.75 |
| Min. cross section (inflexible)(mm²) | 0.2 | Min. stripping length(mm) | 9 | Stripping length (max.)(mm) | 10 |
| No. of rows | 1 | Pins per row | 1 | Nominal voltage(V) | 630 |
| Product size (height)(mm) | 12.50 | Product size (length)(mm) | 9.00 | Product size (width)(mm) | 19.10 |
| Series (connectors) | 235 | Weight(g) | 0.913 | Connection (components) | |
| PCB terminal features | + PUSH WIRE® | PCB terminal type (category) | Spring-loaded terminal | Connector orientation | Parallel (to the PCB) |
| Contact material | Cathode copper | Contact surface | Tin plated | Industrial goods | Yes |
| Wire protection | Yes |
This page is Spring-loaded terminal, 235, part number 235-551/331-000.
You can find the detail information about specifications and dimensions on part number 235-551/331-000.
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
