1-conductor female plug 2092【50-200 Pieces Per Package】
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
| Part Number | Related to |
Standard Unit Price
| Number of pc(s). included in pkg. | Minimum order quantity | Volume Discount | Nominal current (A) | Nominal voltage (V) | Connection direction | Product size (height) (mm) | Product size (length) (mm) | Product size (width) (mm) | Contact spacing (mm) | Max. temperature (°C) | Min. temperature (°C) | Stripping length (max.) (mm) | Total number of pins | Pins per row | Colour | Pin strip type (category) | Connector type | Connector features | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
201.67 € | 100 Pieces Per Package | 1 pack | 26 Days | 10 | 320 | [Other] vertical mount | 13.4 | 10.00 | 35.40 | 5 | +100 | -60 | 10.00 | 2 | 2 | Light grey | Pin enclosure - PCB | Plug | + one-hand locking mechanism | |||
300.61 € | 200 Pieces Per Package | 1 pack | Available | 25 Days | 10 | 320 | [Other] vertical mount | 13.4 | 10.00 | 35.40 | 5 | +100 | -60 | 10.00 | 2 | 2 | Light grey | Pin enclosure - PCB | Plug | + one-hand locking mechanism | ||
218.48 € | 100 Pieces Per Package | 1 pack | 8 Days | 10 | 320 | [Other] vertical mount | 14.40 | 10.00 | 35.40 | 5 | +100 | -60 | 10.00 | 2 | 2 | Light grey | Pin enclosure - PCB | Plug | + one-hand locking mechanism | |||
240.88 € | 200 Pieces Per Package | 1 pack | 25 Days | 10 | 320 | [Other] vertical mount | 15 | 13.40 | 35.40 | 5 | +100 | -60 | 10.00 | 3 | 3 | Light grey | Pin enclosure - PCB | Plug | + one-hand locking mechanism | |||
335.01 € | 200 Pieces Per Package | 1 pack | 25 Days | 10 | 320 | [Other] vertical mount | 15 | 13.40 | 35.40 | 5 | +100 | -60 | 10.00 | 3 | 3 | Light grey | Pin enclosure - PCB | Plug | + one-hand locking mechanism | |||
335.01 € | 200 Pieces Per Package | 1 pack | 25 Days | 10 | 320 | [Other] vertical mount | 15 | 13.40 | 35.40 | 5 | +100 | -60 | 10.00 | 3 | 3 | Light grey | Pin enclosure - PCB | Plug | + one-hand locking mechanism | |||
355.27 € | 200 Pieces Per Package | 1 pack | Available | 8 Days | 10 | 320 | [Other] vertical mount | 20.00 | 13.40 | 35.40 | 5 | - | - | 10.00 | 4 | 4 | Light grey | Pin enclosure - PCB | Plug | + one-hand locking mechanism | ||
| - | 420.87 € | 200 Pieces Per Package | 1 pack | Available | 25 Days | 10 | 320 | [Other] vertical mount | - | 35.4 | 20 | 5 | - | - | - | 4 | 4 | Light grey | Pin enclosure - PCB | Plug | + one-hand locking mechanism | |
| - | 420.87 € | 200 Pieces Per Package | 1 pack | Available | 26 Days | 10 | 320 | [Other] vertical mount | - | 35.4 | 20 | 5 | - | - | - | 4 | 4 | Light grey | Pin enclosure - PCB | Plug | + one-hand locking mechanism | |
370.57 € | 200 Pieces Per Package | 1 pack | Available | 5 Days | 10 | 320 | [Other] vertical mount | 20.00 | 14.40 | 35.40 | 5 | +100 | -60 | 10.00 | 4 | 4 | Light grey | Pin enclosure - PCB | Plug | + one-hand locking mechanism | ||
196.07 € | 100 Pieces Per Package | 1 pack | 8 Days | 10 | 320 | [Other] vertical mount | 25 | 13.40 | 40.40 | 5 | - | - | 10.00 | 5 | 5 | Light grey | Pin enclosure - PCB | Plug | + one-hand locking mechanism | |||
224.08 € | 100 Pieces Per Package | 1 pack | 25 Days | 10 | 320 | [Other] vertical mount | 25 | 13.40 | 40.40 | 5 | - | - | 10.00 | 5 | 5 | Light grey | Pin enclosure - PCB | Plug | + one-hand locking mechanism | |||
224.08 € | 100 Pieces Per Package | 1 pack | 26 Days | 10 | 320 | [Other] vertical mount | 25 | 13.40 | 40.40 | 5 | - | - | 10.00 | 5 | 5 | Light grey | Pin enclosure - PCB | Plug | + one-hand locking mechanism | |||
229.55 € | 100 Pieces Per Package | 1 pack | Available | 25 Days | 10 | 320 | [Other] vertical mount | 25 | 14.40 | 40.40 | 5 | +100 | -60 | 10.00 | 5 | 5 | Light grey | Pin enclosure - PCB | Plug | + one-hand locking mechanism | ||
262.35 € | 100 Pieces Per Package | 1 pack | Available | 25 Days | 10 | 320 | [Other] vertical mount | 30.00 | 13.40 | 40.40 | 5 | - | - | 10.00 | 6 | 6 | Light grey | Pin enclosure - PCB | Plug | + one-hand locking mechanism | ||
294.05 € | 100 Pieces Per Package | 1 pack | Available | 26 Days | 10 | 320 | [Other] vertical mount | 30.00 | 13.40 | 40.40 | 5 | - | - | 10.00 | 6 | 6 | Light grey | Pin enclosure - PCB | Plug | + one-hand locking mechanism | ||
294.05 € | 100 Pieces Per Package | 1 pack | Available | 25 Days | 10 | 320 | [Other] vertical mount | 30.00 | 13.40 | 40.40 | 5 | - | - | 10.00 | 6 | 6 | Light grey | Pin enclosure - PCB | Plug | + one-hand locking mechanism | ||
267.81 € | 100 Pieces Per Package | 1 pack | Available | 8 Days | 10 | 320 | [Other] vertical mount | 30.00 | 14.40 | 40.40 | 5 | +100 | -60 | 10.00 | 6 | 6 | - | Pin enclosure - PCB | Plug | + one-hand locking mechanism | ||
344.33 € | 100 Pieces Per Package | 1 pack | Available | 8 Days | 10 | 320 | [Other] vertical mount | 40.00 | 13.40 | 40.40 | 5 | - | - | 10.00 | 8 | 8 | Light grey | Pin enclosure - PCB | Plug | + one-hand locking mechanism | ||
370.57 € | 100 Pieces Per Package | 1 pack | Available | 26 Days | 10 | 320 | [Other] vertical mount | 40.00 | 13.40 | 40.40 | 5 | - | - | 10.00 | 8 | 8 | Light grey | Pin enclosure - PCB | Plug | + one-hand locking mechanism | ||
425.23 € | 100 Pieces Per Package | 1 pack | Available | 8 Days | 10 | 320 | [Other] vertical mount | 40.40 | 13.40 | 50 | 5 | +100 | -60 | 10.00 | 10 | 10 | Light grey | Pin enclosure - PCB | Plug | + one-hand locking mechanism | ||
402.24 € | 100 Pieces Per Package | 1 pack | 25 Days | 10 | 320 | [Other] vertical mount | 40.40 | 13.40 | 50 | 5 | +100 | -60 | 10.00 | 10 | 10 | Light grey | Pin enclosure - PCB | Plug | + one-hand locking mechanism | |||
402.24 € | 100 Pieces Per Package | 1 pack | 26 Days | 10 | 320 | [Other] vertical mount | 40.40 | 13.40 | 50 | 5 | +100 | -60 | 10.00 | 10 | 10 | Light grey | Pin enclosure - PCB | Plug | + one-hand locking mechanism | |||
357.43 € | 50 Pieces Per Package | 1 pack | 25 Days | 10 | 320 | [Other] vertical mount | 40.40 | 14.40 | 50 | 5 | +100 | -60 | 10.00 | 10 | 10 | Light grey | Pin enclosure - PCB | Plug | + one-hand locking mechanism | |||
458.27 € | 50 Pieces Per Package | 1 pack | 8 Days | 10 | 320 | [Other] vertical mount | 40.40 | 13.40 | 60.00 | 5 | +100 | -60 | 10.00 | 12 | 12 | Light grey | Pin enclosure - PCB | Plug | + one-hand locking mechanism | |||
480.67 € | 50 Pieces Per Package | 1 pack | 26 Days | 10 | 320 | [Other] vertical mount | 40.40 | 13.40 | 60.00 | 5 | +100 | -60 | 10.00 | 12 | 12 | Light grey | Pin enclosure - PCB | Plug | + one-hand locking mechanism | |||
464.99 € | 50 Pieces Per Package | 1 pack | 25 Days | 10 | 320 | [Other] vertical mount | 40.40 | 14.40 | 60.00 | 5 | +100 | -60 | 10.00 | 12 | 12 | Light grey | Pin enclosure - PCB | Plug | + one-hand locking mechanism | |||
319.33 € | 200 Pieces Per Package | 1 pack | 25 Days | 10 | 320 | straight | 13.4 | 10.00 | 16.20 | 5 | - | - | 10.00 | 2 | 2 | Light grey | Pin enclosure - PCB | Pin strip | - | |||
458.27 € | 200 Pieces Per Package | 1 pack | 26 Days | 10 | 320 | straight | 13.4 | 10.00 | 16.20 | 5 | - | - | 10.00 | 2 | 2 | Light grey | Pin enclosure - PCB | Pin strip | - | |||
480.67 € | 200 Pieces Per Package | 1 pack | 8 Days | 10 | 320 | straight | 15 | 13.40 | 16.20 | 5 | - | - | 10.00 | 3 | 3 | Light grey | Pin enclosure - PCB | Pin strip | - | |||
592.72 € | 200 Pieces Per Package | 1 pack | 25 Days | 10 | 320 | straight | 15 | 13.40 | 16.20 | 5 | - | - | 10.00 | 3 | 3 | Light grey | Pin enclosure - PCB | Pin strip | - | |||
592.72 € | 200 Pieces Per Package | 1 pack | 25 Days | 10 | 320 | straight | 15 | 13.40 | 16.20 | 5 | - | - | 10.00 | 3 | 3 | Light grey | Pin enclosure - PCB | Pin strip | - | |||
577.03 € | 200 Pieces Per Package | 1 pack | 8 Days | 10 | 320 | straight | 16.20 | 13.40 | 20 | 5 | - | - | 10.00 | 4 | 4 | Light grey | Pin enclosure - PCB | Pin strip | - | |||
689.08 € | 200 Pieces Per Package | 1 pack | 26 Days | 10 | 320 | straight | 16.20 | 13.40 | 20 | 5 | - | - | 10.00 | 4 | 4 | Light grey | Pin enclosure - PCB | Pin strip | - | |||
689.08 € | 200 Pieces Per Package | 1 pack | 26 Days | 10 | 320 | straight | 16.20 | 13.40 | 20 | 5 | - | - | 10.00 | 4 | 4 | Light grey | Pin enclosure - PCB | Pin strip | - | |||
420.17 € | 100 Pieces Per Package | 1 pack | 26 Days | 10 | 320 | straight | 16.20 | 13.40 | 25.00 | 5 | - | - | 10.00 | 5 | 5 | Light grey | Pin enclosure - PCB | Pin strip | - | |||
397.76 € | 100 Pieces Per Package | 1 pack | 25 Days | 10 | 320 | straight | 16.20 | 13.40 | 30 | 5 | - | - | 10.00 | 6 | 6 | Light grey | Pin enclosure - PCB | Pin strip | - | |||
480.67 € | 100 Pieces Per Package | 1 pack | 26 Days | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | |||
480.67 € | 100 Pieces Per Package | 1 pack | 26 Days | 10 | 320 | straight | 16.20 | 13.40 | 30 | 5 | - | - | 10.00 | 6 | 6 | Light grey | Pin enclosure - PCB | Pin strip | - | |||
577.03 € | 100 Pieces Per Package | 1 pack | 8 Days | 10 | 320 | straight | 16.20 | 13.40 | 40 | 5 | - | - | 10.00 | 8 | 8 | Light grey | Pin enclosure - PCB | Pin strip | - | |||
633.05 € | 100 Pieces Per Package | 1 pack | 25 Days | 10 | 320 | straight | 16.20 | 13.40 | 40 | 5 | - | - | 10.00 | 8 | 8 | Light grey | Pin enclosure - PCB | Pin strip | - | |||
633.05 € | 100 Pieces Per Package | 1 pack | 25 Days | 10 | 320 | straight | 16.20 | 13.40 | 40 | 5 | - | - | 10.00 | 8 | 8 | Light grey | Pin enclosure - PCB | Pin strip | - | |||
722.69 € | 100 Pieces Per Package | 1 pack | 8 Days | 10 | 320 | straight | 16.20 | 13.40 | 50 | 5 | - | - | 10.00 | 10 | 10 | Light grey | Pin enclosure - PCB | Pin strip | - | |||
778.71 € | 100 Pieces Per Package | 1 pack | 25 Days | 10 | 320 | straight | 16.20 | 13.40 | 50 | 5 | - | - | 10.00 | 10 | 10 | Light grey | Pin enclosure - PCB | Pin strip | - | |||
778.71 € | 100 Pieces Per Package | 1 pack | 25 Days | 10 | 320 | straight | 16.20 | 13.40 | 50 | 5 | - | - | 10.00 | 10 | 10 | Light grey | Pin enclosure - PCB | Pin strip | - | |||
397.76 € | 50 Pieces Per Package | 1 pack | 8 Days | 10 | 320 | straight | 16.20 | 13.40 | 60.00 | 5 | - | - | 10.00 | 12 | 12 | Light grey | Pin enclosure - PCB | Pin strip | - | |||
458.27 € | 50 Pieces Per Package | 1 pack | 26 Days | 10 | 320 | straight | 16.20 | 13.40 | 60.00 | 5 | - | - | 10.00 | 12 | 12 | Light grey | Pin enclosure - PCB | Pin strip | - | |||
458.27 € | 50 Pieces Per Package | 1 pack | 26 Days | 10 | 320 | straight | 16.20 | 13.40 | 60.00 | 5 | - | - | 10.00 | 12 | 12 | Light grey | Pin enclosure - PCB | Pin strip | - | |||
386.56 € | 100 Pieces Per Package | 1 pack | 8 Days | 15 | 630 | straight | 35.00 | 13.40 | 39.00 | 7.5 | +100 | -60 | 10.00 | 5 | 5 | Light grey | Socket enclosure - cable | Pin strip | + strap handle | |||
168.05 € | 100 Pieces Per Package | 1 pack | 8 Days | 15 | 630 | straight | 13.4 | 12.50 | 16.20 | 7.5 | - | - | 10.00 | 2 | 2 | Light grey | Pin enclosure - PCB | Pin strip | - | |||
235.28 € | 100 Pieces Per Package | 1 pack | 8 Days | 15 | 630 | straight | 16.20 | 13.40 | 20 | 7.5 | - | - | 10.00 | 3 | 3 | Light grey | Pin enclosure - PCB | Pin strip | - | |||
280.11 € | 100 Pieces Per Package | 1 pack | 8 Days | 15 | 630 | straight | 16.20 | 13.40 | 27.5 | 7.5 | - | - | 10.00 | 4 | 4 | Light grey | Pin enclosure - PCB | Pin strip | - | |||
352.95 € | 100 Pieces Per Package | 1 pack | 5 Days | 15 | 630 | straight | 16.20 | 13.40 | 35.00 | 7.5 | - | - | 10.00 | 5 | 5 | Light grey | Pin enclosure - PCB | Pin strip | - |
Loading...
Basic information
| Cross section (max.)(mm²) | 2.5 | Min. cross section(mm²) | 0.2 | AWG max. | 12 |
|---|---|---|---|---|---|
| AWG (min.) | 24 | No. of rows | 1 | Contact material | Cathode copper |
| Case material | Polyphthalamide (PPA GF) | Connection (components) | Connector contact surface | Tin plated | |
| Connectors | wire-to-board | Series (connectors) | 2092 | Industrial goods | Yes |
Configure
Basic Attributes
-
Nominal current(A)
-
Nominal voltage(V)
-
Connection direction
- straight
- Other
-
Product size (height)(mm)
-
Product size (length)(mm)
-
Product size (width)(mm)
-
Contact spacing(mm)
- 5
- 7.5
-
Max. temperature(°C)
- +100
-
Min. temperature(°C)
- -60
-
Stripping length (max.)(mm)
- 10.00
-
Total number of pins
-
Pins per row
-
Colour
- Light grey
-
Pin strip type (category)
- Pin enclosure - PCB
- Socket enclosure - cable
-
Connector type
- Pin strip
- Plug
-
Connector features
- + one-hand locking mechanism
- + strap handle
Filter by standard shipping days
-
- All
- 5 Days or Less
- 8 Days or Less
- 25 Days or Less
- 26 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
