N disconnect terminal block UTN

Basic Attributes

• Total number of pins(Pole)

  • 1
  • 2

  Clear

• AWG

  • 10 - 4
  • 18 - 2
  • 24 - 8
  • 26 - 12

  Clear

• Clamp width(mm)

  • 5.2
  • 8.2
  • 12.2
  • 15

  Clear

• Connector cross section (fixed)(mm²)

  • 0.14 - 4
  • 0.2 - 10
  • 0.75 - 35
  • 6 - 25

  Clear

• Connector cross-section (flexible)(mm²)

  • 0.14 - 4
  • 0.2 - 10
  • 0.75 - 35
  • 6 - 16

  Clear

• Contamination level

  • 3

  Clear

• Nominal voltage(V)

  • 250
  • 400

  Clear

• Nominal voltage (details)(V)

  • 250
  • 400

  Clear

• Nominal current(A)

  • 24
  • 41
  • 76
  • 110

  Clear

• Nominal current (details)(A)

  • 24
  • 41

  Clear

• Product size (height)(mm)

  • 47.5
  • 49.8
  • 49.9

  Clear

• Product size (width)(mm)

  • 5.2
  • 8.2
  • 12.2
  • 15

  Clear

• Stripping length(mm)

  • 9(max.)
  • 10(max.)
  • 12(max.)
  • 16(max.)

  Clear

• Flammability rating

  • V0
  • V2

  Clear

• Connection (components)

  • Plug & Clip
  • Screws

  Clear

• Insulation material

  • PA

  Clear

• Industrial goods

  • No
  • Yes

  Clear
