Installation ground terminal block UK 6
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
3024753
Basic information
| Total number of pins(Pole) | 2 | Color | Blue | AWG | 24 - 8 |
|---|---|---|---|---|---|
| Clamp width(mm) | 16.4 | Connector cross section (fixed)(mm²) | 0.2 - 10 | Connector cross-section (flexible)(mm²) | 0.2 - 6 |
| Nominal voltage(V) | 400 | Nominal voltage (details)(V) | 250 V (at 10 mm ²) | Nominal current(A) | 57 |
| No. of rows | 1 | Product size (height)(mm) | 47 | Product size (length)(mm) | 42.5 |
| Product size (width)(mm) | 16.4 | Stripping length(mm) | 10(max.) | Flammability rating | V0 |
| Connection (components) | Screws | Connector type (category) | PG terminal | Industrial goods | No |
This page is Installation ground terminal block UK 6, part number 3024753.
You can find the detail information about specifications and dimensions on part number 3024753.
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
