Feed-through terminal block UPCV3K 4-G-7,62
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
1838381
Basic information
| Total number of pins(Pole) | 4 | Color | Grey | AWG | 24 - 12 |
|---|---|---|---|---|---|
| Clamp width(mm) | 7.62 | Connector cross section (fixed)(mm²) | 0.2 - 4 | Connector cross-section (flexible)(mm²) | 0.2 - 4 |
| Nominal voltage(V) | 800 | Nominal current(A) | 20 | No. of rows | 1 |
| Product size (length)(mm) | 74.5 | Product size (width)(mm) | 7.62 | Stripping length(mm) | 10(max.) |
| Flammability rating | V0 | Connection (components) | Screws | Connector type (category) | Continuity |
| Insulation material | PA | Industrial goods | Yes |
This page is Feed-through terminal block UPCV3K 4-G-7,62, part number 1838381.
You can find the detail information about specifications and dimensions on part number 1838381.
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
