Feed-through terminal block ST 16
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Basic information
| Total number of pins(Pole) | 2 | AWG | 24 - 6 | Clamp width(mm) | 12.2 |
|---|---|---|---|---|---|
| Connector cross section (fixed)(mm²) | 0.2 - 25 | Connector cross-section (flexible)(mm²) | 0.2 - 16 | Contamination level | 3 |
| Nominal voltage(V) | 1000 | Nominal current(A) | 76 | No. of rows | 1 |
| Product size (height)(mm) | 51.5 | Product size (length)(mm) | 80 | Product size (width)(mm) | 12.2 |
| Stripping length(mm) | 18(max.) | Flammability rating | V0 | Connection (components) | Pull spring |
| Connector type (category) | Continuity | Insulation material | PA | Industrial goods | Yes |
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
