Klauke 723F Butt joint 16 mm² Not insulated Metal 1 pc(s)
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
723F
Basic information
| Colour | Metal | Contact material | Copper silver plated | Cross-section range | 16 mm² (max) |
|---|---|---|---|---|---|
| Cross section (max.)(mm²) | 16 | Dimensions | (l x d4 x d1) 38 x 9.5 x 6.6 mm | Inside diameter(mm) | 6.6 |
| Insulation type | Not insulated | Manufacturer part # | 723F | Material (details) | Cu according to EN 13600. tin-plated |
| Outside diameter(mm) | 9.5 | Product size (length)(mm) | 38 | Product type | Butt joint |
| Type (manufacturer type) | 723F |
This page is Klauke 723F Butt joint 16 mm² Not insulated Metal 1 pc(s), part number 723F.
You can find the detail information about specifications and dimensions on part number 723F.
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
