Connection Cable PNP

Basic Attributes

• Material Nut

  • stainless steel (1.4404 / 316L) / stainless steel (1.4404 / 316L)
  • Brass, anti-spatter / Brass, anti-spatter
  • Brass, nickel-plated / Brass, nickel-plated
  • diecast zinc / diecast zinc

  Clear

• Protection

  • IP 65; IP 67; IP 68; IP 69K
  • IP 68

  Clear

• Materials

  • Housing: PP grey; Sealing: EPDM
  • Housing: PVC orange; Sealing: EPDM
  • Housing: TPU orange; Sealing: FKM
  • PUR

  Clear

• Protection Class

  • II
  • III

  Clear

• Application

  • hygienic and wet areas in the food industry
  • welding applications

  Clear

• Electrical Connection - Socket

  • Connector: 1 x M8, angled; Locking: brass, nickel-plated; Contacts: gold-plated; Tightening torque: 0.3-0.5 Nm
  • Connector: 1 x M8, angled; Moulded body: TPU, black transparent; Locking: brass, nickel-plated; Sealing: FKM; Contacts: gold-plated; Tightening torque: 0.3-0.5 Nm
  • Connector: 1 x M8, angled; Moulded body: PUR; Locking: brass, nickel-plated; Contacts: gold-plated; Tightening torque: 0.6-0.7 Nm
  • Connector: 1 x M8, angled; Locking: stainless steel (1.4404 / 316L); Contacts: gold-plated; Tightening torque: 0.3-0.5 Nm
  • Connector: 1 x M12, angled; Locking: brass, nickel-plated; Contacts: gold-plated; Tightening torque: 0.6-1.5 Nm
  • Connector: 1 x M12, angled; Moulded body: TPU, black transparent; Locking: brass, anti-spatter; Sealing: FKM; Contacts: gold-plated; Tightening torque: 0.6-1.5 Nm
  • Connector: 1 x M12, angled; Moulded body: TPU, black transparent; Locking: brass, nickel-plated; Sealing: FKM; Contacts: gold-plated; Tightening torque: 0.6-1.5 Nm
  • Connector: 1 x M12, straight; Moulded body: PUR, transparent; Locking: diecast zinc; Sealing: FKM; Contacts: gold-plated; Tightening torque: 0.6-1.5 Nm
  • Connector: 1 x M12, straight; Moulded body: TPU, black transparent; Locking: brass, nickel-plated; Sealing: FKM; Contacts: gold-plated; Tightening torque: 0.6-1.5 Nm
  • Connector: 1 x M12, angled; Moulded body: PP, Halogen-free, black transparent; Locking: stainless steel (1.4404 / 316L); Sealing: EPDM; Contacts: gold-plated; Tightening torque: 0.6-1.5 Nm
  • Connector: 1 x M12, angled; Moulded body: PVC, black transparent; Locking: stainless steel (1.4404 / 316L); Sealing: EPDM; Contacts: gold-plated; Tightening torque: 0.6-1.5 Nm
  • Connector: 1 x M12, straight; Moulded body: PVC, black transparent; Locking: stainless steel (1.4404 / 316L); Sealing: EPDM; Contacts: gold-plated; Tightening torque: 0.6-1.5 Nm

  Clear

• Operating Voltage(V)

  • 10-36 DC
  • 10-30 DC

  Clear

• Ambient Temperature(°C)

  • -25-100
  • -25-90
  • -25-85
  • -25-80

  Clear

• Max. Current Load Total(A)

  • 3
  • 4

  Clear

• Moulded-Body Material

  • PP, Halogen-free / PP, Halogen-free
  • PUR / PUR
  • PVC / PVC
  • TPU / TPU

  Clear

• Special Feature

  • Free from silicone; Gold-plated contacts
  • Free from silicone; Gold-plated contacts; Drag chain suitability
  • Free from silicone; Halogen-free; Gold-plated contacts
  • Free from silicone; Halogen-free; Gold-plated contacts; Drag chain suitability

  Clear

• Dimensions(mm)

  • 10 x 10 x 36
  • 10 x 25 x 25.5
  • 14.5 x 14.5 x 48.5
  • 15.5 x 15.5 x 49
  • 15.5 x 15.5 x 49.5
  • 25 x 10 x 25.5
  • 30.5 x 15.5 x 36.5

  Clear

• Sealing Material

  • EPDM
  • FKM

  Clear

• Display

  • Switching status: 1 x LED, yellow
    operation: 1 x LED, green
  • Switching status: 1 x LED, yellow
    Switching status: 1 x LED, white
    operation: 1 x LED, green
  • Switching status: 2 x LED, yellow
    operation: 1 x LED, green
  • Switching status: 4 x LED, yellow
    operation: 1 x LED, green

  Clear
