Radial insert ball bearings / single row / NPP / eccentric locking collar / adjusting ring / INA
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Part Number
|
|---|
| 0009493610000 |
| 0009493880000 |
| Part Number | Related to |
Standard Unit Price
| Minimum order quantity | Volume Discount | Inner Diameter d (φ) | Outer Diameter D (φ) | Width B (or T) (mm) | Basic Dynamic Load Rating (N) | Basic Load Rating Static Rating (N) | Shoulder dimension d3 (mm) | Shoulder dimension D1 (mm) | Customs tariff — weight (kg) | Product code | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
35.83 € | 1 | 5 Days | 25 | 62 | 32 | 14000 | 7800 | 37.5 | 59.6 | 0.31 | PE25-XL | |||
- | 1 | 5 Days | 20 | 55 | 31.5 | 13600 | 6600 | 33 | 52.6 | 0.25 | PE20-XL |
Loading...
Basic information
| Load Direction | Radial | Size Standard | Metric System | Product type | Radial insert ball bearing |
|---|---|---|---|---|---|
| Ring nut | Yes | Bore shape | Cylindrical | Designator cover / seal | Two zinc-plated sheet steel washers with NBR component between, axially pretensioned sealing lip |
| Width C(mm) | 11.2 | Width with mounting components B1(mm) | 31 | Method of attachment | Fit seat |
| Marking cover / seal | NPP | Rotation direction | Alternating | Central length S(mm) | 23.5 |
| Model series | PE.. | Outer surface design | Adjusting ring | Engineering material | Steel |
| Customs tariff — weight per | 1 | Customs tariff — weight unit | kg | Customs tariff — item number | 84821090 |
| Customs tariff — country of origin | DE |
Configure
Basic Attributes
-
Inner Diameter d(φ)
-
Outer Diameter D(φ)
-
Width B (or T)(mm)
-
Basic Dynamic Load Rating(N)
-
Shoulder dimension d3(mm)
-
Shoulder dimension D1(mm)
-
Customs tariff — weight(kg)
-
Type
-
Filter by CAD data type
- 3D
Filter by standard shipping days
-
- All
- 5 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
