Angular contact ball bearings / double row / 33xx-BD2Z / gap seals on both sides / contact angle 30° / 33xx-BD2Z / similar to DIN 628-3 / FAG
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
| Part Number | Related to |
Standard Unit Price
| Minimum order quantity | Volume Discount | Inner Diameter d (φ) | Outer Diameter D (φ) | Width B (or T) (mm) | Basic Dynamic Load Rating (N) | Maximum Allowable Rotational Speed (1/min) | Load Direction | Basic Load Rating Static Rating (N) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
33.94 € | 1 | Available | 3 Days | 15 | 42 | 19 | 17000 | 13800 | Radial | 10400 | ||
36.20 € | 1 | Available | 3 Days | 17 | 47 | 22.2 | 22500 | 12400 | Radial | 13100 | ||
| - | 41.17 € | 1 | Available | 5 Days | 17 | 47 | 22.2 | - | - | - | - | |
56.90 € | 1 | Available | 5 Days | 20 | 52 | 22.2 | 24600 | 11000 | Radial | 15900 | ||
| - | 56.90 € | 1 | Available | 5 Days | 20 | 52 | 22.2 | - | - | - | - | |
38.37 € | 1 | Available | 3 Days | 20 | 52 | 22.2 | 24600 | 11000 | Radial | 15900 | ||
| - | 43.65 € | 1 | Available | 5 Days | 20 | 52 | 22.2 | - | - | - | - | |
59.80 € | 1 | Available | 5 Days | 25 | 62 | 25.4 | 31500 | 9300 | Radial | 21000 | ||
| - | 59.80 € | 1 | Available | 5 Days | 25 | 62 | 25.4 | - | - | - | - | |
45.85 € | 1 | Available | 3 Days | 25 | 62 | 25.4 | 31500 | 9300 | Radial | 21000 | ||
| - | 52.15 € | 1 | Available | 5 Days | 25 | 62 | 25.4 | - | - | - | - | |
69.28 € | 1 | Available | 5 Days | 30 | 72 | 30.2 | 43000 | 7800 | Radial | 29500 | ||
| - | 69.28 € | 1 | Available | 5 Days | 30 | 72 | 30.2 | - | - | - | - | |
54.86 € | 1 | Available | 3 Days | 30 | 72 | 30.2 | 43000 | 7800 | Radial | 29500 | ||
70.28 € | 1 | Available | 3 Days | 35 | 80 | 34.9 | 55000 | 6800 | Radial | 36500 | ||
| - | 70.28 € | 1 | Available | 3 Days | 35 | 80 | 34.9 | - | - | - | - | |
63.97 € | 1 | Available | 3 Days | 35 | 80 | 34.9 | 55000 | 6800 | Radial | 36500 | ||
| - | 72.76 € | 1 | Available | 5 Days | 35 | 80 | 34.9 | - | - | - | - | |
101.60 € | 1 | Available | 5 Days | 40 | 90 | 36.5 | 67000 | 6000 | Radial | 48500 | ||
| - | 101.60 € | 1 | Available | 5 Days | 40 | 90 | 36.5 | - | - | - | - | |
92.03 € | 1 | Available | 5 Days | 40 | 90 | 36.5 | 67000 | 6000 | Radial | 48500 | ||
| - | 92.03 € | 1 | Available | 5 Days | 40 | 90 | 36.5 | - | - | - | - | |
100.80 € | 1 | Available | 3 Days | 45 | 100 | 39.7 | 72000 | 5500 | Radial | 54000 | ||
| - | 100.80 € | 1 | Available | 3 Days | 45 | 100 | 39.7 | - | - | - | - | |
157.73 € | 1 | Available | 5 Days | 50 | 110 | 44.4 | 93000 | 4900 | Radial | 70000 | ||
| - | 157.73 € | 1 | Available | 5 Days | 50 | 110 | 44.4 | - | - | - | - | |
141.75 € | 1 | Available | 5 Days | 50 | 110 | 44.4 | 93000 | 4900 | Radial | 70000 | ||
| - | 124.62 € | 1 | Available | 3 Days | 50 | 110 | 44.4 | - | - | - | - | |
187.25 € | 1 | Available | 5 Days | 55 | 120 | 49.2 | 116000 | 4350 | Radial | 88000 | ||
| - | 187.25 € | 1 | Available | 5 Days | 55 | 120 | 49.2 | - | - | - | - | |
154.83 € | 1 | Available | 3 Days | 55 | 120 | 49.2 | 116000 | 4350 | Radial | 88000 | ||
| - | 176.13 € | 1 | Available | 5 Days | 55 | 120 | 49.2 | - | - | - | - |
Loading...
Configure
Basic Attributes
-
Inner Diameter d(φ)
-
Outer Diameter D(φ)
-
Width B (or T)(mm)
-
Basic Dynamic Load Rating(N)
-
Load Direction
- Radial
-
Type
- 3302
- 3303
- 3304
- 3305
- 3306
- 3307
- 3308
- 3309
- 3310
- 3311
-
Filter by CAD data type
- 3D
Filter by standard shipping days
-
- All
- 3 Days or Less
- 5 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
