THR male header 2091【100-200 Pieces Per Package】
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
| Part Number | Related to |
Standard Unit Price
| Number of pc(s). included in pkg. | Minimum order quantity | Volume Discount | Number of pins (Pole) | Pins per row | Product size (height) (mm) | Product size (length) (mm) | Product size (width) (mm) | Connector features | Connector orientation | Connector type | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
103.07 € | 200 Pieces Per Package | 1 pack | 7 Days | 2 | 2 | 12.40 | 9.00 | 19.9 | - | Perpendicular (to the PCB) | Plug, vertical mount | |||
240.88 € | 200 Pieces Per Package | 1 pack | 32 Days | 3 | 3 | 19.90 | 12.40 | 24.50 | for THR soldering | Perpendicular (to the PCB) | Plug, vertical mount | |||
235.28 € | 200 Pieces Per Package | 1 pack | 7 Days | 5 | 5 | 19.50 | 12.40 | 19.9 | - | Perpendicular (to the PCB) | Plug, vertical mount | |||
319.33 € | 200 Pieces Per Package | 1 pack | 33 Days | 5 | 5 | 19.90 | 12.40 | 31.50 | for THR soldering | Perpendicular (to the PCB) | Plug, vertical mount | |||
145.65 € | 100 Pieces Per Package | 1 pack | 8 Days | 6 | 6 | 19.90 | 12.40 | 23 | - | Perpendicular (to the PCB) | Plug, vertical mount | |||
184.87 € | 100 Pieces Per Package | 1 pack | 33 Days | 6 | 6 | 19.90 | 12.40 | 35.00 | - | Perpendicular (to the PCB) | Plug, vertical mount | |||
190.47 € | 100 Pieces Per Package | 1 pack | 7 Days | 8 | 8 | 19.90 | 12.40 | 30.00 | - | Perpendicular (to the PCB) | Plug, vertical mount | |||
235.28 € | 100 Pieces Per Package | 1 pack | 33 Days | 8 | 8 | 19.90 | 12.40 | 42 | - | Perpendicular (to the PCB) | Plug, vertical mount | |||
235.28 € | 100 Pieces Per Package | 1 pack | 7 Days | 10 | 10 | 19.90 | 12.40 | 37 | - | Perpendicular (to the PCB) | Plug, vertical mount | |||
280.11 € | 100 Pieces Per Package | 1 pack | 33 Days | 10 | 10 | 19.90 | 12.40 | 49.00 | - | Perpendicular (to the PCB) | Plug, vertical mount | |||
280.11 € | 100 Pieces Per Package | 1 pack | 8 Days | 12 | 12 | 19.90 | 12.40 | 44 | - | Perpendicular (to the PCB) | Plug, vertical mount | |||
103.07 € | 200 Pieces Per Package | 1 pack | 7 Days | 2 | 2 | 14.8 | 9.00 | 17.5 | - | Parallel (to the PCB) | Plug, horizontal mount | |||
196.07 € | 200 Pieces Per Package | 1 pack | 32 Days | 2 | 2 | 17.50 | 14.80 | 21 | for THR soldering | Parallel (to the PCB) | Plug, horizontal mount | |||
151.25 € | 200 Pieces Per Package | 1 pack | 7 Days | 3 | 3 | 14.8 | 12.50 | 17.5 | - | Parallel (to the PCB) | Plug, horizontal mount | |||
240.88 € | 200 Pieces Per Package | 1 pack | 33 Days | 3 | 3 | 17.50 | 14.80 | 24.50 | for THR soldering | Parallel (to the PCB) | Plug, horizontal mount | |||
190.47 € | 200 Pieces Per Package | 1 pack | 7 Days | 4 | 4 | 16.00 | 14.80 | 17.5 | - | Parallel (to the PCB) | Plug, horizontal mount | |||
280.11 € | 200 Pieces Per Package | 1 pack | 33 Days | 4 | 4 | 17.50 | 14.80 | 28 | for THR soldering | Parallel (to the PCB) | Plug, horizontal mount | |||
235.28 € | 200 Pieces Per Package | 1 pack | 32 Days | 5 | 5 | 17.50 | 14.80 | 19.50 | - | Parallel (to the PCB) | Plug, horizontal mount | |||
319.33 € | 200 Pieces Per Package | 1 pack | 8 Days | 5 | 5 | 17.50 | 14.80 | 31.50 | for THR soldering | Parallel (to the PCB) | Plug, horizontal mount | |||
145.65 € | 100 Pieces Per Package | 1 pack | 8 Days | 6 | 6 | 17.50 | 14.80 | 23 | + sleeve | Parallel (to the PCB) | Plug, horizontal mount | |||
190.47 € | 100 Pieces Per Package | 1 pack | 7 Days | 8 | 8 | 17.50 | 14.80 | 30.00 | - | Parallel (to the PCB) | Plug, horizontal mount | |||
235.28 € | 100 Pieces Per Package | 1 pack | 33 Days | 8 | 8 | 17.50 | 14.80 | 42 | for THR soldering | Parallel (to the PCB) | Plug, horizontal mount | |||
235.28 € | 100 Pieces Per Package | 1 pack | 7 Days | 10 | 10 | 17.50 | 14.80 | 37 | - | Parallel (to the PCB) | Plug, horizontal mount | |||
280.11 € | 100 Pieces Per Package | 1 pack | 32 Days | 10 | 10 | 17.50 | 14.80 | 49.00 | for THR soldering | Parallel (to the PCB) | Plug, horizontal mount | |||
280.11 € | 100 Pieces Per Package | 1 pack | 7 Days | 12 | 12 | 17.50 | 14.80 | 44 | - | Parallel (to the PCB) | Plug, horizontal mount | |||
323.81 € | 100 Pieces Per Package | 1 pack | 7 Days | 12 | 12 | 17.50 | 14.80 | 56.00 | for THR soldering | Parallel (to the PCB) | Plug, horizontal mount |
Loading...
Basic information
| Color | Light grey | Contact spacing(mm) | 3.50 | No. of rows | 1 |
|---|---|---|---|---|---|
| Nominal current(A) | 10 | Nominal voltage(V) | 160 | Series (connectors) | 2091 |
| Connection (components) | Connectors | wire-to-board | Contact material | Cathode copper | |
| Contact surface | Tin plated | Insulation material | Polyphthalamide (PPA GF) | Pin strip type (category) | Pin enclosure - PCB |
| Industrial goods | Yes |
Configure
Basic Attributes
-
Number of pins(Pole)
-
Pins per row
-
Product size (height)(mm)
-
Product size (length)(mm)
-
Product size (width)(mm)
-
Connector features
-
Connector orientation
- Parallel (to the PCB)
- Perpendicular (to the PCB)
-
Connector type
- Plug, horizontal mount
- Plug, vertical mount
Filter by standard shipping days
-
- All
- 7 Days or Less
- 8 Days or Less
- 32 Days or Less
- 33 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
